26 | Installation, Operating, and Maintenance Manual
Appendix F1: Pressurized Variable Speed Flow Center Submittals
Technical Data
Circulators:
Grundfos UPS26-99 & Magna GEO variable spd. (requires controller)
Cabinet:
High Impact Polystyrene plastic
Insulation:
CFC-free, polyurethane foam
Valves:
1" Full-port, 3-Way, 4-Position flushing and isolation/service valve,
Brass body and spool, NBR seals, stainless steel retaining ring.
Electrical Data
UPS26-99 motor: 208-230V, 60 Hz, single phase, 2-pole UL and CSA approved, internal thermal
overload protection, insulation class F, three speed
Magna GEO motor: 208-230V, 50/60 Hz, single phase, 2-pole, ETL
CSA requirements), electronically protected, insulation class F, variable speed
*Data is maximum for UPS26-99; Magna GEO varies with RPM.
Pump Performance Curves
Grundfos Magna GEO 32-140 and UPS26-99 (pumps in series)
80
[239]
75
[224]
70
[209]
65
[194]
60
[179]
55
[164]
50
[149]
45
Pumps operate in series
[134]
40
between these curves*
[119]
35
to maintain flow rate
[105]
30
or temperature diff.
[90]
25
[75]
20
[60]
15
[45]
10
[30]
5
[15]
0
0
5
10
[0.32
0.63
Curves are manufacturer's reported averages using water at 68°F [20°F].
Submittal Data
FLV Series Variable Speed Pressurized Flow Center, Double Pump
Project Name:
Contractor:
Engineer:
Order Number:
Additional Information:
Amps @
Watts @
230V*
230V*
*UPS26-99 is a constant speed pump; Magna GEO is a variable
speed pump. When both pumps are running, the Magna GEO
operates between duty cycles shown below to maintain
set flow rate or temperature difference.
Magna GEO + UPS26-99 (high speed)
Magna GEO (lowest duty cycle -- highest flow/head)
Magna GEO (highest duty cycle -- lowest flow/head)
15
20
25
30
0.95
1.26
1.58
1.89
Flow (U.S. GPM) [l/s]
approved (meets UL and
C/US
35
40
45
50
2.21
2.52
2.84
3.15]
Rev. 05JUL2016
Max. Fluid Temperature: 140°F [60°C]
Min. Fluid Temperature: 20°F [-7°C]
Max. Oper. Press.: 145 psi [1 Mpa]
Min. Operating Press.: 1.3 psi [9 kPa]
Max. Ambient Air Temp: 104°F [40°C]
Approved Antifreeze
Propylene Glycol
Ethanol
Methanol
Mounting
Flow Center is designed for indoor
installation only.
Flow Center must be installed with
the pump's motor shaft horizontal.
Do not install flow center with the
pump's motor shaft vertical.
The terminal box should be located in
one of the following orientations:
Magna GEO
UPS26-99
GEO-FLO PRODUCTS CORPORATION
905 Williams Park Drive
Bedford, IN 47421
Phone: 812-275-8513 Fax: 812-275-8523
www.geo-flo.com
SD 1299 rev. 24SEP2013
