Grundfos Geo-Flo Universal Pump Controller Installation, Operating And Maintenance Manual page 27

Appendix F1: Pressurized Variable Speed Flow Center Submittals
Dimensional Data
A
A B
Inches 13-1/4 10-3/16
CM 33.6 25.9
Fluid connections are Flo-Link™ double O-ring style. Transition fittings are not included with the flow
center packaging. Typically, PE fusion x Flo-Link is used on the ground loop connections. A Geo-Flo
hose kit designed for Flo-Link connections includes transition fittings for heat pump connections.
GEO-FLO UNIVERSAL PUMP CONTROLLER: UPC-GEO | 25
B
E
H
D
C D E F
8-1/2 9-7/16 4-3/4 12-1.2
21.6 24.0 12.0 31.7
G
I
F
C
G H I
2 5
3/8"
DRIVE
SOCKET
5.0 12.7
GEO-FLO PRODUCTS CORPORATION
905 Williams Park Drive
Bedford, IN 47421
Phone: 812-275-8513 Fax: 812-275-8523
www.geo-flo.com
WEIGHT
LBS KG
26 12
SD 1298 rev. 21SEP2013
