Appendix E: Controller Mounting Template
6"
This document must be printed full-scale to properly mark the mounting-hole locations. The
Page Scaling in the Print dialog box in Adobe Acrobat must be set to None. The 6-inch line can
be used as reference to ensure the document has been printed full-scale.
GEO-FLO UNIVERSAL PUMP CONTROLLER: UPC-GEO | 23
SUGGESTED MOUNTING
HOLE LOCATIONS
SUGGESTED MOUNTING
HOLE LOCATIONS
