WWAN module
For a list of available WWAN modules, see
The WWAN module is located on the back of the system board. The WWAN module is secured with one Phillips
screw and has two connected antennas. You must remove the system board to replace the WWAN module.
NOTE:
The procedure to replace the WWAN module must be performed by an HP technician.
To remove the WWAN module:
1.
Prepare the computer for disassembly (see
2.
Remove the hand strap (see
3.
Remove the rear cover (see
4.
Disconnect the battery (see
5.
Remove the display (see
6.
Remove the system board (see
7.
Lift the foam (1) and tape (2) from atop the WWAN module.
8.
Remove the Phillips screw (1) that secures the module to the system board, and then pull the module
out of the socket (2).
Illustrated parts catalog on page
Preparing to disassemble the computer on page
Hand strap on page
38).
Backplate on page
39).
Battery on page
44).
Display on page
40).
System board on page
14.
46).
37).
WWAN module
49
