Removing the carry case from the mobility head unit

1. Remove the mobility head unit from the dock if it is attached.
2. Remove the MSR from the mobility head unit if it is attached.
3. Pull one corner on the left side of the mobility head unit (1) from the carry case, and then pull the other
corner on the left side of the mobility head unit (2) from the carry case. Then slide the right of the
mobility head unit (3) out of the carry case.
Attaching an I/O connectivity base to the HP Engage Go
Convertible System
You can attach an I/O connectivity base to the bottom of the mobility system dock's stability base.
1. Turn off the mobility system properly through the operating system, and turn off any external devices.
2. Disconnect the power cords from the mobility system and I/O connectivity base.
IMPORTANT:
as the system is plugged into an active AC outlet. You must disconnect the power cord and wait
approximately 30 seconds for the power to drain to avoid damage to the internal components.
26 Chapter 5 Hardware configurations and upgrades
Regardless of the power-on state, voltage is always present on the system board as long
