Table Of Contents; Notes And Specifications - Electro-Harmonix Super Switcher User Manual

T
ABLE OF
Notes and Specifications
Controls and Connections
Ins, Outs, Sends and Returns
Illuminated Buttons
Footswitches and LEDs
Boost and Value Knobs
Preset Mode
Instant Access Mode
Control Functions
MIDI Control
MIDI Receive Message Tables
Setup Menu
Restoring Factory Settings
Warranty Information and Compliance
N
OTES AND
Audio input impedance: 2Mbufferorboostonly

Audio output impedance for each output: 470bufferonly

Audio output impedance for each output: 1Kbooston

Current draw: 150mA

Maximum input signal level: +11 dBu

Bypass: Mechanical relay true bypass switching

C
ONTENTS
S
PECIFICATIONS
