MIDI CONTROL

PROGRAM CHANGE MESSAGES
The Super Switcher can send MIDI program change (PC) messages with
preset changes. For each preset, the Super Switcher can send one
program change message on any one channel or on all MIDI channels
(OMNI).
ENABLE PC MESSAGE:
• With the required preset active, press and release the PC
illuminated button to engage or disengage the PC message for the
selected preset. When the button is lit, the PC message is enabled
for the given preset so that each time the preset is recalled, the
PC message is output from the MIDI OUT port.
EDIT PC MESSAGE & CHANNEL:
• With the required preset active, press and hold the PC illuminated
button. The PC button will begin to blink and the character display
will show
PCN
represents the PC message to be sent. Turning VALUE will
•
ChL
show
• With the character display showing
character display will show a three-digit number.
• Turn VALUE to select the PC message number. The range is 000-
127.
• Press VALUE again to go back to
• Turn VALUE so the display shows
• Turn VALUE to select the PC send channel. The range is 01-16 and
ONI
for Omni, which sends the PC message on all channels.
• Press and hold VALUE to exit PC message edit.
CONTROL CHANGE MESSAGES
The Super Switcher can send MIDI Control Change (CC) messages—aka
continuous controller messages—with preset changes. For each preset,
the Super Switcher can send one full CC message. The Super Switcher
can send the message on any one channel or OMNI.
PCN
.
, which represents the PC message's MIDI channel.
PCN
PCN
.
ChL
. Press and release VALUE.
9
, press VALUE. The
