Preset Mode - Electro-Harmonix Super Switcher User Manual

P M
RESET ODE
ENGAGE PRESETS
Preset Mode is the main default mode for the Super Switcher.
When in Preset Mode, the PRESET footswitch LED will be lit, and the
character display will show the current BANK number.
In Preset Mode each footswitch: 1-8, engages or disengages the saved
preset: 1-8 for the current bank.
SELECTING BANKS
To change the current bank press the BANK UP or BANK DOWN
footswitch. VALUE can also be turned to change banks.
When a bank change is made, the bank number in the character display
will begin to blink. The new bank is not active until you press the VALUE
encoder button. The newly selected bank will load with no preset
selected.
Alternatively, both a new bank and a preset can be loaded by pressing
footswitches 1-8 while the bank numbers are blinking. The new preset
will load and the display will stop blinking.
The display will also stop blinking if you return to the current bank
without activating a new preset.
EDITING/SAVING PRESETS
The Super Switcher automatically saves any edits that are made to the
current preset.
Presets are saved at the time you press footswitch 1-8. Whether you
disengage the current preset or directly engage a different preset, any
edits will be saved to the preset that was being worked on.
When a preset is engaged, press the illuminated buttons to enable or
disable effects loops and MIDI messages. The control functions such as
BOOST, CTRL 1 and CTRL 2 can also be saved per preset.
6
