Electro-Harmonix Satisfaction Plus Operating Instructions

Modernized Vintage Fuzz

Congratulations on your purchase of the Satisfaction Plus, an

expanded take on the classic fuzz sounds of the 1960s. Still in a

compact chassis, the Satisfaction Plus adds a Bias control for

wilder tones, a Fat switch for a broader sound, and a versatile

tone knob for more sonic sculpting.

Connect your guitar to the INPUT jack of the Satisfaction Plus and the AMP

Your Satisfaction Plus is now ready to play.

A good starting point is to turn all knobs to their 12'oclock positions,

then set the toggle switch to NORM for the classic bright fuzz-tone, or

to FAT for a fuller sound.

Voltage: 9VDC

This device may be powered with an Electro-Harmonix 9.6DC-200, MOP-D10, or S8 power supply. Use of the

wrong adapter or a plug with the wrong polarity may damage the device and void the warranty. Do not exceed

18VDC on the power plug. Power supplies rated for less than 10mA can cause the device to act unreliably.

Operating Instructions

POWER SUPPY REQUIREMENTS:

Current: 5mA

Polarity: Center-Negative

Battery: 9V

Table of Contents

Need help?

Do you have a question about the Satisfaction Plus and is the answer not in the manual?

Page 1 Polarity: Center-Negative Battery: 9V This device may be powered with an Electro-Harmonix 9.6DC-200, MOP-D10, or S8 power supply. Use of the wrong adapter or a plug with the wrong polarity may damage the device and void the warranty. Do not exceed...
Page 2 Controls and Connections 1. ATTACK Knob Controls the amount of input gain and distortion. As you turn this knob clockwise, the Satisfaction Plus ranges from mild drive to saturated fuzz. 2. BIAS Knob Controls the signal bias going into the first transistor stage of the Satisfaction Plus.
Page 3 4. VOL Knob Sets the output level of the Satisfaction Plus. 5. FAT/NORM switch In the NORM position, the Satisfaction Plus has the same overall circuitry as the original Satisfaction pedal. Push the switch to FAT for a bigger, bassier fuzz sound that still cuts through a mix.
Page 4 WARRANTY INFORMATION Please register online at www.ehx.com/product-registration or complete and return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at its discretion, a product that fails to operate due to defects in materials or workmanship for a period of one year from date of pur- chase.
