- Page 1 3300 HULL MOUNT SUB-BOTTOM PROFILER U S E R H A R D W A R E M A N U A L 0016732_REV_C 5/1/2018 EdgeTech 4 Little Brook Road West Wareham, MA 02576 Tel: (508) 291-0057 Fax: (508) 291-2491...
- Page 2 The information, figures, and specifications in this manual are proprietary and are issued in strict confidence on condition that they not be copied, reprinted, or disclosed to a third party, either wholly or in part, without the prior, written consent of EdgeTech. Any reproduction of EdgeTech supplied software or file sharing is strictly prohibited.
-
Page 3: Attention - Read This First
ATTENTION – READ THIS FIRST! All personnel involved with the installation, operation, or maintenance of the equipment described in this manual should read and understand the warnings and cautions provided below. CAUTION! This equipment contains devices that are extremely sensitive to static electricity. -
Page 4: Hardware Variations And Compatibility
HARDWARE VARIATIONS AND COMPATIBILITY The 3300 Hull Mount Sub-Bottom Profiler contains both standard and proprietary hardware. At times, EdgeTech may change the standard components due to their availability or performance improvements. Although the component manufacturers—along with their models and styles—may change from unit to unit, replacement parts will generally be interchangeable. -
Page 5: About This Document
Purpose of this Manual The purpose of this manual is to provide the user with information on the setup and use of EdgeTech’s 3300 Hull Mount Sub-Bottom Profiler. Although this manual encompasses the latest operational features of the 3300 Hull Mount Sub-Bottom Profiler, some features may be periodically upgraded. -
Page 6: Warranty Statement
All equipment manufactured by EdgeTech is warranted against defective components and workmanship for a period of one year after shipment. Warranty repair will be done by EdgeTech free of charge. Shipping costs are to be borne by the customer. Malfunction due to improper use is not covered in the warranty, and EdgeTech disclaims any liability for consequential damage resulting from defects in the performance of the equipment. -
Page 7: Software Service Overview
Software Updates and Enhancements EdgeTech customers can download new software releases with all modifications and enhancements from the EdgeTech ftp site. Major software issues, should they occur, will be reported directly to the customer. New software releases consist of the following: •... -
Page 8: Returned Material Authorization
Refer to RMA number on all documentation and correspondences. All returned materials must be shipped prepaid. Freight collect shipments will not be accepted. All equipment should be adequately insured for shipping, but equipment belonging to EdgeTech must be insured for full value. - Page 9 CUSTOMER SERVICE Customer service personnel at EdgeTech are always eager to hear from users of our products. Your feedback is welcome, and is a valuable source of information which we use to continually improve these products. Therefore, we encourage you to contact EdgeTech Customer Service to offer any suggestions...
-
Page 10: Company Background
— for the acquisition of underwater data, including marine, estuarine, and coastal applications — for over 50 years. EdgeTech responds to the needs of the Scientific, Naval, and Offshore communities by providing industry- leading equipment — such as Sub-Bottom Profilers, Side Scan Sonar, Acoustic Releases, USBL Positioning Systems, and Bathymetric Systems —... -
Page 11: Table Of Contents
TABLE OF CONTENTS ATTENTION – READ THIS FIRST! ......................iii HARDWARE VARIATIONS AND COMPATIBILITY .................. iv ABOUT THIS DOCUMENT ........................v Purpose of this Manual ..........................v Liability ..............................v Warnings, Cautions, and Notes ......................... v Revision History ............................v WARRANTY STATEMENT ........................ - Page 12 4.2.6 Deck Unit Placement ......................4-3 4.3 Hull Mount Array Installation ....................... 4-3 4.4 Connecting the System ......................... 4-5 5.0: OPERATION ..........................5-1 5.1 Activating the System ........................5-1 5.2 File Format ............................ 5-1 5.2.1 EdgeTech’s Native JSF Format ....................5-1...
- Page 13 ZDA – Time & Date ......................... C-6 HDG - Heading, Deviation and Variation ................C-6 EVT – Event * Annotation (EdgeTech Custom) ..............C-7 EMA: Event, Set Mark & Annotation (EdgeTech Custom) ............C-8 C.5 Serial Port Connections ......................... C-9 C.6 Troubleshooting ..........................C-9...
-
Page 14: List Of Figures
LIST OF FIGURES Figure 1-1: Overall System Diagram (2x2 Configuration) ................1-4 Figure 1-2: 3200 Rack Mount Processor ....................1-5 Figure 1-3: T/R Box (Interior & Exterior) ....................1-6 Figure 1-4: Spider Array ..........................1-7 Figure 1-5: Single Transducer........................1-7 Figure 1-6: 2x2 Sea Chest Array ......................... - Page 15 Table C-8: ZDA – Time and Date ........................ C-6 Table C-9: HDG: Heading, Deviation, and Variation .................. C-6 Table C-10: EVT – Event * Annotation (EdgeTech Custom) ............... C-7 Table C-11: EMA: Event, Set Mark & Annotation ..................C-8 Table C-12: 9 Male Pin Out ........................C-9...
-
Page 17: Overview
The 3300-HM SBP system generates virtually no side lobes, due to the wide bandwidth of the sweep frequency. This bandwidth has an effect of smearing the side lobes of the transducer, resulting in a beam pattern with almost no side lobes. -
Page 18: Transducer Array
1.1.2 Transducer Array Acoustic projectors in the 3300-HM SBP system are constructed from wideband, piston-type transducers and the acoustic receivers are a discrete line array of PZT crystals. The acoustic hull-mounted transducers are designed for profiling at ship speeds varying from zero (drifting) to 7 knots. -
Page 19: Reduction Of Side Lobes And High Repeatability
is nearly preserved. Thus, even after being attenuated by sand, the acoustic pulse has approximately the same resolution as an un-attenuated pulse. 1.1.5 Reduction of Side Lobes and High Repeatability Full Spectrum sonar has the unique ability to reduce side lobes in the effective transducer aperture. The wide bandwidth of the sweep frequency has the effect of smearing the side lobes of the transducer and thus achieving a beam pattern with virtually no side lobes. -
Page 20: Figure 1-1: Overall System Diagram (2X2 Configuration)
1.0: OVERVIEW Figure 1-1: Overall System Diagram (2x2 Configuration) -
Page 21: Deck Unit
1.2.1 Deck Unit LCD Monitor DISCOVER Software Keyboard 19-inch Rack Mount Enclosure 3200-XS Topside Processor Trackball Power Amplifier Figure 1-2: 3200 Rack Mount Processor The Deck Unit consists of a processor, amplifier, and monitor as shown in 1-2. The 19-inch Tack IGURE Mount enclosure consists of a computer-based controller containing a Sonar Interface Board (SIB). -
Page 22: T/R Box Assembly
CHIRP pulses. A startup file launches the sonar.exe program automatically every time the system is booted. The 3300-HM SBP interfaces with the ship’s Navigation (GPS, IMU, etc), triggers, motion and heave sensors, echo sounder, and printers. -
Page 23: Transducer Array
1.2.3 Transducer Array The transducers for the 3300-HM SBP are mounted in a two-dimensional array inside a closed well on board a survey vessel. These transducers act as both projectors and hydrophones. EdgeTech offers a range of transducer arrays, each designed to provide various beam widths. In general, lower operating frequencies require multiple receiving arrays and larger transducers, therefore requiring different array sizes. -
Page 24: Applications
(2 contacts) connectors. All Transducer Cables connect to a T/R Box. 1.3 Applications The 3300-HM SBP has the unique ability to strip-away the world’s oceans during imaging and provide high resolution sub-bottom images. This tool lends itself to various tasks that include: •... -
Page 25: Specifications
2.0: SPECIFICATIONS The 3300-HM SBP system is composed of a deck unit, T/R Box, and hull-mounted transducer array. This section details the sub-components of the system and provides their specifications. For information related to the provided DISCOVER software, refer to 0019800 in the Manual Folder. -
Page 26: Amplifier Specifications
If this occurs, the system will stop transmitting and DISCOVER will display a ‘HOT’ error message. When a safe operating temperature is restored, the amplifier will resume normal operation. 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 27: Power Output
The specifications for the Power Amplifier (PN 0010855) are shown in 2-3, 2-4, and 2-5. ABLE ABLE ABLE 2.1.2.1 Power Output SPECIFICATION VALUE 4-ohm Bridge 5,600 W 8-ohm Bridge 6,000 W Table 2-3: Power Amp Specifications: Power Output 2.1.2.2 Performance SPECIFICATION VALUE Frequency Response (at 1 watt, 20 Hz –... -
Page 28: Construction
Table 2-7: Physical Specifications of T/R Box 2.3 Technical Drawings An assembly drawing of the T/R Box is provided in 2-2. IGURE A wiring diagram of the T/R Box is provided in 2-3. IGURE 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 29: Figure 2-2: T/R Box Assembly Drawing - 0007914
Figure 2-2: T/R Box Assembly Drawing - 0007914... -
Page 30: Figure 2-3: T/R Box Wiring Diagram - 0004638
Figure 2-3: T/R Box Wiring Diagram - 0004638... -
Page 31: Spider & Array Specifications
2.4 Spider & Array Specifications The standard transducers for the 3300-HM SBP system have a good frequency response from 2 kHz to 16 kHz. Multiple transducers are mounted to give various beam width options. Specifications for the array are given in and a wiring diagram for the spider box is provided in 2-4. -
Page 32: Figure 2-4: Spider Wiring Diagram - 0009969
2.0: SPECIFICATIONS Figure 2-4: Spider Wiring Diagram - 0009969... -
Page 33: Kt-216H Specifications:
show the specifications for the KT-216H and KT-106D arrays, respectively: ABLE ABLE KT-216H Specifications: SPECIFICATION VALUE Frequency Range: 2 - 12 kHz 2 - 5 kHz, 100 ms 2 - 6 kHz, 40 ms 2 - 8 kHz2 - 8 kHz, 40 ms, Wide Band (WB) Pulses (user selected): 2 - 10 kHz, 20 ms 2 - 12 kHz, 20 ms... -
Page 34: Figure 2-5 : Kt-106 Non-Symmetrical Array Configurations
(4.5 kHz) to determine resolution and penetration. The size of the array is another contributing factor, as low frequency efficiency goes up as the side of the array is increased due to increased directivity. 5x Kt-106 7x Kt-106 Figure 2-5 : KT-106 Non-Symmetrical Array Configurations 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 35: Array Sizes
2-11 2.5.1 Array Sizes Selection of array size depends on transducer type (KT-216 or KT-106) and the geological survey application. The important decision parameter is the water depth in which the system is to be used. For most deployments to 3000 meters, a 4 x 4 array will provide the needed performance. A 2 x 2 array should be considered only for coastal application and water depths to 300 meters. -
Page 36: Figure 2-6: Deck Cable, T/R Box, And Spider Wiring Diagram (2X2 Configuration)
2-12 Figure 2-6: Deck Cable, T/R Box, and Spider Wiring Diagram (2x2 Configuration) -
Page 37: Figure 2-7: Single Transducer Drawing - 0013579
2-13 Figure 2-7: Single Transducer Drawing - 0013579... -
Page 38: Figure 2-8: 2X2 Transducer Configuration - 0011720
2-14 Figure 2-8: 2x2 Transducer Configuration - 0011720... -
Page 39: Figure 2-9: 3X3 Transducer Configuration - 0015753
2-15 Figure 2-9: 3x3 Transducer Configuration - 0015753... -
Page 40: Figure 2-10: 4X4 Transducer Configuration - 0013960
2-16 Figure 2-10: 4x4 Transducer Configuration - 0013960... -
Page 41: Figure 2-11: 5X5 Transducer Configuration - 0016713
2-17 Figure 2-11: 5x5 Transducer Configuration - 0016713... -
Page 42: Signal Cable Specifications
AMPLIFIER OUTPUT 1 DF1000 DATA (SUBSCAN ONLY) AMPLIFIER OUTPUT 2 PRE-AMPLIFIER INPUT CHANNEL A PRE-AMPLIFIER COMMON Table 2-13: Deck Cable Pinouts Figure 2-12: Topside Unit Deck Cable for Hull Mount Systems (Female) Amphenol #97-3106A-20-33F 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 43: Figure 2-13: Female Marshal Connector - 86-5Fc (Deck Cable To T/R Box Connection)
2-19 FUNCTION AMPLIFIER OUTPUT 1 AMPLIFIER OUTPUT 2 PREAMPLIFER COMMON PRE-AMPLIFIER SIGNAL RS-232 DATA + 12 VDC SEA GROUND RS-232 COMMON Figure 2-13: Female Marshal Connector – 86-5FC (Deck Cable to T/R Box Connection) Table 2-14: Deck CABLE Connector Pinouts Figure 2-14: Male Marshal Connector –... -
Page 44: Figure 2-15: Deck Cable Schematic - 0002976
2-20 Figure 2-15: Deck Cable Schematic - 0002976... -
Page 45: Controls & Connections
3.0: CONTROLS & CONNECTIONS This section describes the controls and indicators, along with the connections for the 3300-HM SBP. 3.1 Deck Unit Controls and Indicators The deck unit controls and indicators are as follows, and are shown in 3-1: IGURE POWER SUPPLY: Rocker switch. -
Page 46: Figure 3-1: Topside Front Panel Controls And Connections
System Indicator DVD R/RW Drive Hard Disk Hard Disk Reset Button Indicator Connectors Ready Indicators Power, Bridge, & CH1 Dial CH2 Dial Figure 3-1: Topside Front Panel Controls and Connections Data Indicators (defunct) (defunct) 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 47: Deck Unit Connections
3.2 Deck Unit Connections The topside deck unit connections are as follows, and are shown in . The wiring diagram can be IGURE seen in 3-3: IGURE TRACKBALL: USB on front or rear panel connects to the trackball. KEYBOARD: USB on front or rear panel connects to the keyboard. SEA CABLE: 11-Pin female bulkhead connector. -
Page 48: Figure 3-2: Topside Rear Panel Controls And Connections
TRIGGER OUT Ethernet1 Ethernet2 TRIGGER IN Connector COM 1-NAV COM 3 Connectors Connectors Connector Connector Connector Mini Display Port Video Connectors Sonar Data Main I/O Connector POWER AMP OUT TX1 indicator Power Supply POWER AMP OUT USB 3.1 Ports USB3 Ports TX2 indicator 12 VDC OUT TO PREAMP test point... -
Page 49: Figure 3-3: Rear Panel Schematic - 0004957
Figure 3-3: Rear Panel Schematic - 0004957... -
Page 51: Installation
4.0: INSTALLATION This section explains how to unpack, inspect, and install the 3300-HM SBP system. It describes placement considerations for the topside and transducer arrays, along with power requirements. Refer to the PN 0016695 for a more detailed explanation of 3300-HM SBP installation. -
Page 52: Topside Installation
4.2.1 Power Supply The system power requirements are 120–220 VAC, 50/60 Hz. For the 3300-HM SBP Topside Processor, the input voltage is auto sensing. For the Power Amplifier, you must select 120 VAC or 220 VAC operation manually. -
Page 53: Navigation Interface
EdgeTech document PN 0016695. The transducer arrays for the 3300-HM SBP system are mounted to the bottom of the survey vessel in a “Sea Chest.” This chest is filled with fresh water in order to protect the array from corrosion, while providing a medium for the sub-bottom sonar signal to travel through. - Page 54 The sides of the enclosure should be high enough to allow inspection of the array; EdgeTech recommends the sides of the box be at least 30 cm higher than the top of the transducers. There should be a minimum of 5 cm between the sides of the transducers and the sides of the sea chest.
-
Page 55: Connecting The System
3 meters of the tank. The T/R Box contains a pre-amp, matching transformer, and T/R switch. The T/R Box enclosure is plastic and approximately 18 cm high by 18 cm wide by 12 cm deep. A standard 50-meter 3300-HM SBP deck cable connects the T/R Box to the 3300-HM SBP Topside Processor. -
Page 57: Operation
5.2 File Format Data is archived to the hard drive of the system in two formats, EdgeTech’s native format JSF and the SEG- Y format. The SEG-Y recording can be turned on or off in the software but the EdgeTech Format is always recorded. -
Page 58: Palette File Format
Here is an example table for a linear gray step wedge type palette: 5.3 Triggering and Coupling To avoid interference, the 3300-HM SBP system supports the following different type of triggering Modes: Internal Trigger: In this mode, the user may specify the ping rate in Hertz (e.g. 3Hz) or ping range (in Meters). -
Page 59: Maintenance
6.0: MAINTENANCE The EdgeTech 3300-HM SBP system is ruggedly designed and built from reliable, long lasting components to reduce maintenance to a minimum. To insure proper and continuing service of the system some periodic maintenance is recommended. 6.1 Hard Drive Disk The system contains a standard SATA hard drive for storing programs and configuration information. -
Page 61: Troubleshooting
Having recorded raw data available for analysis by EdgeTech engineers will often speed up the resolution of suspected problems. Such files may be sent to EdgeTech in USB or if small as email attachments. Many system control and setup parameters are recorded in these raw data files which will assist in problem diagnosis. -
Page 62: Figure 7-1: Graph Display Tab
7.0 TROUBLESHOOTING Figure 7-1: Graph Display Tab 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... - Page 63 Save to File [Push button and Edit Window]: The displayed graph data can be saved to a disk file for sending to EdgeTech Technical Support, for analysis. Enter a file save name in the edit window. (Hint: Use pause check box to freeze display, to make sure of the data being saved.) NOTE: ONLY the data being displayed is saved, i.e.
-
Page 64: System Does Not Operate
• Power the Internal Rear Panel Power Cables from the inside of the power outlet (in the rear of the system) are connected to both the amplifier and 3300-HM SBP Control Unit. • The main power cable is installed and connected to a clean power source. -
Page 65: Symptom / Probable Cause
Measure each output with scope o-scope Damaged Tiger SB Re-seat and then swap in spare PCB. acquisition PCB Tap on the 3300-HM SBP transducers to confirm the Bad connection problem. Under normal operation, there should be Unit generates audible some effect on the display. -
Page 66: Poor Image Quality Or Performance Issues
Amp not turned on, plugged in or bad Check all including TX with o-scope IF_DIAG Tiger SB Acquisition board issue Check Errors in Sonar, Consult EdgeTech NO_SONAR_DEVICE Tiger SB Acquisition board cable issue Check PCB and cabling Table 7-3: Troubleshooting Sonar Errors... -
Page 67: A.0: System Restore
A.0: SYSTEM RESTORE The following section outlines the procedures for backing up and restoring the system drive. CAUTION! All data will be lost upon restoring the system to factory settings. Be sure to backup all data before preforming the procedure below. 1. -
Page 69: B.0: Faq: Frequently Asked Questions
3. How does the system interface to a navigation device? 3300-HM SBP system interfaces to Navigation inputs via one of the available RS-232 communication ports. 4. How do the environmental conditions affect the performance of the system? - Page 70 B: FAQ 3300-HM SBP is operated in this area, the acoustic from the aerated water is reflected back to its source, as in the case discussed in the preceding paragraph. 3300-HM SBP is designed to operate in a horizontal position relative to the sea floor.
-
Page 71: C.0: Navigation Systems
2.0/2.1, or 2.3) data language. GPS receivers can be connected by a serial cable (provided by the GPS manufacturers) to the EdgeTech topside through a standard 9- pin serial port. Refer to sub-section B.5 Serial Port Connections for the pin out of the 9-pin serial connector. -
Page 72: Port Selection
RMC is best, as it contains both time and date, whereas the other position strings do not. If a ZDA message is used as well, this will not matter. However, for a single message, RMC is the best choice 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 73: Gll - Geographic Position - Latitude/Longitude
GLL – Geographic Position – Latitude/Longitude $--GLL,xxxx.xxx,a,yyyyyy.yyy,b,hhmmss.ss,A*hh<CR><LF> ASCII DESCRIPTION Degrees|Minutes.decimal - 2 fixed digits of degrees, 2 fixed digits of minutes and a variable number xxxx.xxx of digits for decimal fractions of minutes. Leading zeros always included for degrees and minutes to maintain fixed length. -
Page 74: Guu - Geographic Position - X And Y Coordinates
2 fixed digits of minutes, 2 fixed digits for seconds and a variable number of digits for decimal fractions of seconds. Always pad with leading zeros. Table C-6: GGA – Global Positioning System Fix Data 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 75: Rma - Recommended Minimum Specific Loran-C Data
RMA – Recommended Minimum Specific Loran-C Data Position, course, and speed from a Loran-C receiver $--RMA,A,llll.ll,a,yyyyy.yy,a,d.d,.e.e,f.f,g.g,h.h,j,k*hh<CR><LF> For fields see NMEA 0183 Specification RMC – Recommended Minimum Specific GNSS Data Time, Date, Position, course and speed provided from a GNSS receiver $--RMC,hhmmss.ss,A,llll.ll,a,yyyyy.yy,a,d.d,e.e,ddmmyy,g.g,j,k*hh<CR>... -
Page 76: Zda - Time & Date
Add Easterly deviation (E) to Magnetic sensor Reading - Subtract Westerly deviation (W) from Magnetic Sensor Reading To obtain True Heading: Add Easterly variation (E) to Magnetic Heading - Subtract Westerly variation (W) from Magnetic Heading 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C... -
Page 77: Evt - Event * Annotation (Edgetech Custom
Event annotation or just annotation message up to 80 Message characters long with a maximum number of messages being 10 Table C-10: EVT – Event * Annotation (EdgeTech Custom) NOTES: This message should only be used if it is imperative that the event mark number be externally controlled, otherwise the $EGEVT message should be used. -
Page 78: Ema: Event, Set Mark & Annotation (Edgetech Custom
C: NAVIGATION SYSTEMS EMA: Event, Set Mark & Annotation (EdgeTech Custom) Event mark number and annotation provided by an integrated navigation system $ETEMA,NNNNNN, <Message>,**hh<CR><LF> ASCII DESCRIPTION NNNNNN Mark number to use for this event. Message Event annotation message up to 23 characters long Table C-11: EMA: Event, Set Mark &... -
Page 79: Serial Port Connections
Ring Indicator (RI) input Table C-12: 9 Male Pin Out The following outlines the different pins from the comport connection that EdgeTech processor uses for communication: Pin # 2: (usually brown) is Receive (which would connect to the transmit pin on the GPS). This connection will take the position data from the GPS for use in the DISCOVER software. - Page 80 7. The main white HyperTerminal window becomes completely visible, hopefully with GPS data scrolling upward. Every sentence must begin with a dollar sign and five letters. If the screen is blank, this means no data is coming in through the port. 3300 HULL MOUNT SUB-BOTTOM PROFILER 0016732_REV_C...
- Page 81 C-11 8. When finished viewing the screen, select "Exit" from the File menu. When asked if you want to disconnect now, click on Yes. When asked if you want to save session, click on No. Repeat the above steps for other COMs, replacing COM1 with COM2, COM3 and COM4. If none of these will reveal GPS input, then the problem lies in the physical serial port, the GPS receiver, or the connection between the two.
