Teknik 5421120 Assembly Instructions For Return On Left

L-shaped desk
Hide thumbs

Advertisement

Quick Links

Download this manual
www.teknikoffice.co.uk
L-Shaped Desk
Clifton Place Collection | Model 5421120
Share your journey!
Teknik
Assembly
Instructions for
Return on Left
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5421120 and is the answer not in the manual?

Questions and answers

Related Manuals for Teknik 5421120

Summary of Contents for Teknik 5421120

  • Page 1 Teknik www.teknikoffice.co.uk Assembly Instructions for Return on Left L-Shaped Desk Clifton Place Collection | Model 5421120 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Share your journey!
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-58 Hammer Not actual size Français 59-65 Español 66-72 Electric drill with 3/16" bit (ONLY in indicated step) Safety 73-74 Warranty...

  • Page 3: Part Identifi Cation

    Part Identifi cation å NOTE: Part PP will not be used in the return on left assembly. Page 3...

  • Page 4: Hardware Identifi Cation

    Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. LONG EXTENSION LONG EXTENSION SHELF SLIDER SET - 1 RAIL - 2 SLIDE - 2 (EXTENSION SET SHOWN SEPARATED) RIGHT CABINET EXTENSION RAIL - 2 EXTENSION SLIDE - 2 RAIL - 3 (EXTENSION SET...
  • Page 5 Hardware Identifi cation å å Screws are shown actual size. You may receive extra hardware with your unit. Screws are shown actual size. You may receive extra hardware with your unit. ANGLED HEAD STRAIGHT HEAD LARGE HIDDEN SMALL HIDDEN CAM - 65 CAM - 20 CAM SCREW - 65 CAM SCREW - 20...

  • Page 6: D Return

    Step 1 Assemble your unit on a carpeted fl oor or on the empty carton å to avoid scratching your unit or the fl oor. Arrow Push fi fty-eight HIDDEN CAMS (15) into the ENDS (A and B), å UPRIGHT (C), RETURN UPRIGHT (D), SHELVES (G), BOTTOMS (H, I, and J), BACKS (K and L), RETURN BACK (N), SHORT UPRIGHT (P), LONG UPRIGHT (Q), BRACES (S and T), and RETURN LEFT END (OO).
  • Page 7 Step 2 Turn twenty ANGLED HEAD CAM SCREWS (16) into the å exact holes shown in the ENDS (A and B), UPRIGHT (C), and RETURN LEFT END (OO). Angled head (20 used) Page 7...
  • Page 8 Step 3 Peel the STICKERS from the LARGE APPLIQUE CARD (27) and å stick one onto each metal insert in the BOTTOMS (H, I and J). Some assembly (and snacks) required. (12 used) Page 8...
  • Page 9 Step 4 Turn eight FEET (NN) into the SMALL BOTTOMS (H and J). å NOTE: Do not overtighten the FEET. å Then, turn eight ADJUSTABLE GLIDES (23) into the FEET (NN). å NOTE: Turn the ADJUSTABLE GLIDES completely in. Final å...
  • Page 10 Step 5 Insert four SHORT WOOD DOWELS (20) into the SMALL å BOTTOMS (H and J). Fasten four BOTTOM RAILS (MM) to the SMALL BOTTOMS (H å and J). Use eight BLACK 1-1/8" FLAT HEAD SCREWS (29). NOTE: Be sure the SHORT WOOD DOWELS in the SMALL å...
  • Page 11 Step 6 Separate the LONG EXTENSION SLIDES (3) from the LONG EXTENSION RAILS (2) as shown in the enlarged å diagram below. Be prepared, the parts are greasy. Fasten two LONG EXTENSION RAILS (2) to the ENDS (A and B). Use six BLACK 1/2" PAN HEAD SCREWS (31). å...
  • Page 12 Step 7 Fasten the CABINET RAILS (6 and 7) to the ENDS (A and B). å Use twelve BLACK 1/2" FLAT HEAD SCREWS (32). Roller end Roller end Use these holes. Use these holes. Roller end Edge with HIDDEN CAMS Roller end BLACK 1/2"...
  • Page 13 Step 8 Insert two LONG WOOD DOWELS (19) into the exact å holes shown in the LEFT END (B). Fasten the SMALL BOTTOM (H) to the LEFT END (B). å Tighten two HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the LEFT END å...
  • Page 14 Step 9 Insert four LONG WOOD DOWELS (19) into the exact holes shown in the LEFT END (B). å Fasten the SMALL BACK (K) and the BRACES (S) to the LEFT END (B). Tighten four HIDDEN CAMS. å NOTE: Be sure the LONG WOOD DOWELS in the LEFT END insert into the SMALL BACK and BRACES. å...
  • Page 15 Step 10 Insert six LONG WOOD DOWELS (19) into the RIGHT END (A). å Fasten the RIGHT END (A) to the SMALL BOTTOM (H), SMALL å BACK (K), and BRACES (S). Tighten six HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the RIGHT END å...
  • Page 16 Step 11 Turn six ANGLED HEAD CAM SCREWS (16) into the exact å holes shown in the RETURN UPRIGHT (D). Angled head Page 16...
  • Page 17 Step 12 Separate the EXTENSION SLIDES (5) from the EXTENSION RAILS (4) as shown in the enlarged diagram below. Be å prepared, the parts are greasy. Fasten two EXTENSION RAILS (4) to the RETURN UPRIGHT (D) and RETURN LEFT END (OO). Use six BLACK 1/2" å...
  • Page 18 Step 13 Fasten the CABINET RAILS (6 and 7) to the RETURN å UPRIGHT (D) and RETURN LEFT END (OO). Use six BLACK 1/2" FLAT HEAD SCREWS (32). Roller end Roller end Use these holes. Use these holes. Roller end BLACK 1/2"...
  • Page 19 Step 14 Fasten the RETURN SMALL BACK (L) to the RETURN å SMALL BOTTOM (J). Use two BLACK 1-1/2" FLAT HEAD SCREWS (28). BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) Edge without HIDDEN CAMS S u r f a c H I D D E N...
  • Page 20 Step 15 Insert four LONG WOOD DOWELS (19) into the exact å holes shown in the RETURN UPRIGHT (D). Fasten the RETURN SMALL BOTTOM (J) and RETURN å SMALL BACK (L) to the RETURN UPRIGHT (D). Tighten four HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the å...
  • Page 21 Step 16 Fasten the RETURN BRACE (T) to the RETURN UPRIGHT (D). å Tighten two HIDDEN CAMS. Rounded edge Surface without HIDDEN CAMS Page 21...
  • Page 22 Step 17 Insert four LONG WOOD DOWELS (19) into the RETURN å LEFT END (OO). Fasten the RETURN LEFT END (OO) to the RETURN SMALL å BOTTOM (J), RETURN SMALL BACK (L), and RETURN BRACE (T). Tighten six HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the RETURN å...
  • Page 23 Step 18 Fasten the UPRIGHT (C) to one of the SHELVES (G). Use å two BLACK 1-1/2" FLAT HEAD SCREWS (28). Finished edge S u r f a c H I D D E N i t h Finished edge i t h f a c S u r...
  • Page 24 Step 19 Fasten the other SHELF (G) to the UPRIGHT (C). Tighten å two HIDDEN CAMS. Finished edge S u r f a c H I D D E N i t h Page 24...
  • Page 25 Step 20 Fasten the BOTTOM (I) to the UPRIGHT (C). Use two å BLACK 1-1/2" FLAT HEAD SCREWS (28). Rounded edge S u r f a c H I D D E N i t h BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 25...
  • Page 26 Step 21 Carefully turn the assembly over onto its front edges. å Insert four LONG WOOD DOWELS (19) into the exact holes shown in the RETURN BACK (N). å Fasten the RETURN BACK (N) to the UPRIGHT (C), SHELVES (G), and BOTTOM (I). Use ten BLACK 1-1/2" FLAT HEAD å...
  • Page 27 Step 22 Carefully lay the assembly onto its back. å Turn three FEET (NN) into the BOTTOM (I). å NOTE: Do not overtighten the FEET. å Then, turn three ADJUSTABLE GLIDES (23) into the FEET (NN). å NOTE: Turn the ADJUSTABLE GLIDES completely in. Final å...
  • Page 28 Step 23 Insert four SHORT WOOD DOWELS (20) into the BOTTOM (I). å Fasten two LONG BOTTOM RAILS (LL) to the BOTTOM (I). Use six å BLACK 1-1/8" FLAT HEAD SCREWS (29). NOTE: Be sure the SHORT WOOD DOWELS in the BOTTOM å...
  • Page 29 Step 24 Turn six ANGLED HEAD CAM SCREWS (16) into the exact å holes shown in the RETURN UPRIGHT (D). Insert four LONG WOOD DOWELS (19) into the exact holes å shown in the RETURN UPRIGHT (D). Angled head (6 used) Page 29...
  • Page 30 Step 25 NOTE: You may need someone's help in this step. å Fasten the RETURN UPRIGHT (D) to the SHELF (G), å BOTTOM (I), and RETURN BACK (N). Tighten six HIDDEN CAMS. NOTE: Be sure the LONG WOOD DOWELS in the å...
  • Page 31 Step 26 NOTE: Be sure to position the RETURN TOP (F) exactly å as shown. Turn twelve ANGLED HEAD CAM SCREWS (16) into the å exact holes shown in the RETURN TOP (F). Angled head Large hole Page 31...
  • Page 32 Step 27 NOTE: Be sure to position the RETURN TOP exactly as shown. å Insert two SHORT WOOD DOWELS (20) into the exact holes shown in the RETURN TOP (F). å Fasten a TOP RAIL (R) to the RETURN TOP (F). Use two BLACK 1-1/8" FLAT HEAD SCREWS (29). å...
  • Page 33 Step 28 Fasten the UPRIGHTS (P and Q) to the RETURN TOP (F). å Use four BLACK 1-1/2" FLAT HEAD SCREWS (28). Edge with HIDDEN CAMS i t h f a c S u r BLACK 1-1/2" FLAT HEAD SCREW (4 used in this step) Large hole Page 33...
  • Page 34 Step 29 With someone's help, carefully stand the return assembly å upright and place it near its fi nal location. Pro Tip: Lift with your legs. And, you know, Insert two LONG WOOD DOWELS (19) into the exact holes shown å...
  • Page 35 Step 30 NOTE: Be sure to position the BACK (M) exactly as shown. å Turn four ANGLED HEAD CAM SCREWS (16) into the exact å holes shown in the BACK (M). Angled head Push seven HIDDEN CAMS (15) into the exact holes shown å...
  • Page 36 Step 31 NOTE: You may need someone's help in this step. å Insert four LONG WOOD DOWELS (19) into the exact holes å shown in the BACK (M). Fasten the BACK (M) to the BOTTOM (I) and RETURN å BACK (N). Tighten four HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the BACK inserts å...
  • Page 37 Step 32 Turn two ANGLED HEAD CAM SCREWS (16) into the exact å holes shown in the LEFT END (B). Insert two LONG WOOD DOWELS (19) into the exact holes å shown in the LEFT END (B). Angled head Page 37...
  • Page 38 Step 33 NOTE: You may need someone's help in this step. å Fasten the LEFT END (B) to the BACK (M). Tighten two å HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the LEFT END å insert into the holes in the BACK Page 38...
  • Page 39 Step 34 NOTE: Be sure to position the TOP (E) exactly as shown. å Turn fi fteen ANGLED HEAD CAM SCREWS (16) into the å exact holes shown in the TOP (E). Then, insert two SHORT WOOD DOWELS (20) into the å...
  • Page 40 Step 35 Fasten the SHELF SLIDER SET (1) to the TOP (E). Use å four BLACK 9/16" LARGE HEAD SCREWS (30). NOTE: Be sure to use the center hole in the å SHELF SLIDERS. BLACK 9/16" LARGE HEAD SCREW (4 used in this step) The tabs on the SHELF SLIDERS should be closer to this edge.
  • Page 41 Step 36 Fasten the KEYBOARD SHELF (O) to the SHELF å SLIDERS on the TOP (E). Use four BLACK 9/16" PAN HEAD SCREWS (31). BLACK 1/2" PAN HEAD SCREW (4 used in this step) Rounded edge Page 41...
  • Page 42 Step 37 NOTE: You may need someone's help in this step. å Insert four LONG WOOD DOWELS (19) into the exact holes å shown in the ENDS (A and B) and UPRIGHTS (P and Q). Fasten the TOP (E) to the ENDS (A and B), BACKS (K and M), å...
  • Page 43 Step 38 Insert twenty SMALL HIDDEN CAMS (17) into the å DRAWER SIDES (Y, Z, BB, CC, GG, HH, JJ, and KK). Arrow (20 used) The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 43...
  • Page 44 Step 39 Turn twenty STRAIGHT HEAD CAM SCREWS (18) into å the DRAWER FRONTS (U, V, W, and X). Straight head (20 used) Page 44...
  • Page 45 Step 40 With the palm of your hand, tap the DRAWER BOTTOM down into the groove. fi n i s h r f a Be sure the DRAWER BOTTOM inserts into the Groove DRAWER FRONT groove. Fasten the SMALL DRAWER SIDES (Y and Z) to the Slide the DRAWER BOTTOM (EE) into the grooves in the å...
  • Page 46 Step 41 Fasten the DRAWER SLIDES (8 and 9) to the SMALL å DRAWER SIDES (Y and Z). Use six BLACK 1/2" FLAT HEAD SCREWS (32). Fasten a PULL (22) to the SMALL DRAWER FRONT (U). å Use two SILVER 1/2" FLAT HEAD SCREWS (33). BLACK 1/2"...
  • Page 47 Step 42 With the palm of your hand, tap the DRAWER BOTTOM down into the groove. fi n i s h r f a Be sure the DRAWER Groove BOTTOM inserts into the DRAWER FRONT groove. Fasten the DRAWER SIDES (BB and CC) to the DRAWER Slide the DRAWER BOTTOM (EE) into the grooves in the å...
  • Page 48 Step 43 Fasten the DRAWER SLIDES (8 and 9) to the DRAWER å SIDES (BB and CC). Use six BLACK 1/2" FLAT HEAD SCREWS (32). Fasten a PULL (22) to the DRAWER FRONT (V). Use two å SILVER 1/2" FLAT HEAD SCREWS (33). Repeat this step for the other drawer.
  • Page 49 Step 44 With the palm of your hand, tap the DRAWER BOTTOM down into the groove. fi n i s h r f a Be sure the DRAWER BOTTOM inserts into the Groove DRAWER FRONT groove. Fasten the LARGE DRAWER SIDES (GG and HH) to Slide the LARGE DRAWER BOTTOM (FF) into the grooves å...
  • Page 50 Step 45 Fasten two LONG EXTENSION SLIDES (3) to the LARGE å DRAWER SIDES (GG and HH). Use six BLACK 1/2" PAN HEAD SCREWS (31). Fasten a PULL (22) to the LARGE DRAWER FRONT (W). Use å two SILVER 1/2" FLAT HEAD SCREWS (33). Open end Use these holes.
  • Page 51 Step 46 Push the LONG FILE GLIDES (13) onto the LARGE å DRAWER SIDES (GG and HH). Slide two FILE HANGERS (11) onto the LONG FILE å GLIDES on the LARGE DRAWER SIDES (GG and HH). Page 51...
  • Page 52 Step 47 Fasten the FRONT FILE GLIDE (10) to the RETURN å DRAWER FRONT (X). Use four BLACK 1/2" PAN HEAD SCREWS (31). BLACK 1/2" PAN HEAD SCREW (4 used in this step) Page 52...
  • Page 53 Step 48 With the palm of your hand, tap the DRAWER BOTTOM down into the groove. fi n i s h r f a Be sure the DRAWER BOTTOM inserts into the Groove DRAWER FRONT groove. Fasten the RETURN DRAWER SIDES (JJ and KK) to Slide the DRAWER BOTTOM (EE) into the grooves in the å...
  • Page 54 Step 49 Fasten two EXTENSION SLIDES (5) to the RETURN DRAWER å SIDES (JJ and KK). Use six BLACK 1/2" PAN HEAD SCREWS (31). Fasten a PULL (22) to the RETURN DRAWER FRONT (X). Use two å SILVER 1/2" FLAT HEAD SCREWS (33). Open end Use these holes.
  • Page 55 Step 50 Push the BACK FILE GLIDE (12) onto the LARGE DRAWER BACK (II). å Push the SHORT FILE GLIDES (14) onto the RETURN DRAWER SIDES (JJ and KK). å Slide the FILE HANGERS (11) onto the FILE GLIDES on the RETURN DRAWER FRONT (X) and LARGE DRAWER BACK (II). å...
  • Page 56 Step 51 Insert four GROMMETS (25) into the large holes in å the UPRIGHTS (C and D) and RETURN BACK (N). Insert four GROMMETS WITH CAPS (24) into the å large holes in the TOPS (E and F). (4 used) Page 56...
  • Page 57 Step 52 Position your unit in its fi nal location. å NOTE: To raise a corner of the unit, turn the ADJUSTABLE å GLIDE counter-clockwise. To lower a corner, turn the ADJUSTABLE GLIDE clockwise. To insert the DRAWERS (U and V) into your unit, tip the å...

  • Page 58: Safety

    Step 53 Peel the STICKERS from the APPLIQUE CARD (26) and stick them onto å each visible hole, HIDDEN CAM, or over the head of each visible SCREW. NOTE: Please read the back pages of the instruction booklet for important å...
  • Page 59 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves or drawers. •...
