- Page 1 Teknik www.teknikoffice.co.uk Get all organized and stuff . Credenza Clifton Place Collection | Model 5421317 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-28 Français 29-32 Skip the power trip. This time. Español 33-36 Safety 37-38 Warranty WARNING Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or death.
- Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. RIGHT END (1) LARGE BOTTOM (1) DRAWER BACK (1)
- Page 4 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. STRAIGHT HEAD SHORT WOOD LONG WOOD WOOD SMALL HIDDEN CAM - 8 CAM SCREW - 8 DOWEL - 4 DOWEL - 34 DOWEL - 12 Straight head ADJUSTABLE HINGE BRACKET - 2...
- Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push thirty HIDDEN CAMS (1) into the ENDS (A and B), å UPRIGHT (C), SHELF (G), BACKS (E, F, and O ), and BOTTOMS (I and J).
- Page 6 Step 2 Turn thirty ANGLED HEAD CAM SCREWS (2) into the å ENDS (A and B), UPRIGHT (C), and TOP (D). NOTE: The UPRIGHT (C) will have four ANGLED HEAD å SCREWS on one surface and six on the opposite surface. Angled head (30 used) Remember:...
- Page 7 Step 3 Separate the EXTENSION SLIDES (Y) from the å EXTENSION RAILS (X) as shown in the enlarged diagram below. Be prepared, the parts are greasy. Fasten the EXTENSION RAILS (X) to the LEFT END (B) and å UPRIGHT (C). Use six BLACK 1/2" PAN HEAD SCREWS (23). NOTE: For each EXTENSION RAIL, turn a SCREW into å...
- Page 8 Step 4 Peel an applique from the LARGE APPLIQUE CARD (14) å and stick one on each large hole in the BOTTOMS (I and J). Flip the BOTTOMS (I and J) over. å Turn and tighten six FEET (W) into the threaded holes in å...
- Page 9 Step 5 Insert eight SHORT WOODEN DOWELS (7) into the å BOTTOMS (I and J). Fasten the LONG BOTTOM MOLDINGS (K) to the å LARGE BOTTOM (I). Use four BLACK 1-1/8" FLAT HEAD SCREWS (22). Fasten the SHORT BOTTOM MOLDINGS (L) to the å...
- Page 10 Step 6 Insert two WOOD DOWELS (6) into the edge of the å SHELF (G). Fasten the SHELF (G) to the UPPER BACK (E). Use two å BLACK 1-1/2" FLAT HEAD SCREWS (21). NOTE: Be sure the WOOD DOWELS in the SHELF insert å...
- Page 11 Step 7 Insert two WOOD DOWELS (6) into the edge of the å LOWER BACK (O). Fasten the LOWER BACK (O) to the BOTTOM (I). Use two å BLACK 1-1/2" FLAT HEAD SCREWS (21). NOTE: Be sure the WOOD DOWELS in the LOWER BACK å...
- Page 12 Step 8 Insert four LONG WOOD DOWELS (5) into the edge of å the LOWER BACK (O). Fasten the UPPER BACK (E) to the LOWER BACK (O), by å pushing it onto the WOOD DOWELS in the LOWER BACK. Lay your unit onto the BACKS (E and O) to prepare for the å...
- Page 13 Step 9 Insert six WOOD DOWELS into the LEFT END (B). å Fasten the LEFT END (B) to the SHELF (G), BACKS (E and O), å Just breathe. and BOTTOM (I). Tighten six HIDDEN CAMS. It's going to be ok. NOTE: Be sure the WOOD DOWELS in the LEFT END å...
- Page 14 Step 10 Insert six WOOD DOWELS (6) into the UPRIGHT (C). å Fasten the UPRIGHT (C) to the SHELF (G), BACKS (E and O), å and BOTTOM (I). Tighten six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the UPRIGHT å...
- Page 15 Step 11 Insert a WOOD DOWEL (6) into the hole in the edge of å the BACK (F). Fasten the SMALL BOTTOM (J) to the BACK (F). Use two å BLACK 1-1/2" FLAT HEAD SCREWS (21). NOTE: Be sure the WOOD DOWEL in the BACK inserts å...
- Page 16 Step 12 Insert four WOOD DOWELS (6) into the UPRIGHT (C). å Fasten the BACK (F) and SMALL BOTTOM (J) to the å UPRIGHT (C). Tighten four HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the UPRIGHT å insert into the BACK and SMALL BOTTOM. Page 16...
- Page 17 Step 13 Fasten the HINGE BRACKETS (11) to the RIGHT END (A) å exactly as shown in the upper diagram. Use the SCREWS in the brackets. Insert four WOOD DOWELS (6) into the RIGHT END (A). å Fasten the RIGHT END (A) to the BACK (F) and SMALL å...
- Page 18 Step 14 Insert four SHORT WOODEN DOWELS (7) into the TOP (D). å Now might be a Fasten the TOP MOLDINGS (M and N) to the TOP (D). å good time to refresh Use four BLACK 1-1/8" FLAT HEAD SCREWS (22). your drink.
- Page 19 Step 15 Carefully stand your unit upright. å Push a GROMMET into the UPRIGHT (C) and BACK (F). å Insert nine WOOD DOWELS (6) into the ENDS (A and B), å UPRIGHT (C), and BACKS (E and F). Fasten the TOP (D) to the ENDS (A and B), UPRIGHT (C), å...
- Page 20 Step 16 Fasten the NOTCHED FILE GLIDE (19) to the DRAWER å FRONT (U). Use six BLACK 1/2" PAN HEAD SCREWS (23). BLACK 1/2" PAN HEAD SCREW (6 used in this step) Notch Page 20...
- Page 21 Step 17 Turn eight STRAIGHT HEAD CAM SCREWS (4) into the å DRAWER FRONT (U). Push eight SMALL HIDDEN CAMS (3) into the large holes in å the DRAWER SIDES (P and R) and DRAWER BRACES (T). Straight head (8 used) Arrow Arrow Hole...
- Page 22 Step 18 Surface with HIDDEN CAMS f a c s u r n i s h U n fi Groove Fasten the DRAWER SIDES (P and R) and the DRAWER å Slide the DRAWER BOTTOM (S) into the grooves å BRACES (T) to the DRAWER FRONT (U).
- Page 23 Step 19 Fasten the EXTENSION SLIDES (Y) to the å DRAWER SIDES (P and R). Use six BLACK 1/2" PAN HEAD SCREWS (23). Fasten a PULL (8) to the DRAWER FRONT (U). Use two å SILVER 1/2" FLAT HEAD SCREWS (24). Open end Use these holes.
- Page 24 Step 20 Push two SHORT FILE GLIDES (17) onto the top edges of å the DRAWER SIDES (P and R). If you're doing this to help a friend, don't Push the LONG FILE GLIDE (18) onto the top edge of the å...
- Page 25 Step Step 21 Fasten the HINGES (12) to the DOOR (V). Use four SILVER 1/2" FLAT HEAD SCREWS (24). å Fasten the PULL (8) to the DOOR (V). Use two SILVER 1/2" FLAT HEAD SCREWS (24). å Fasten the HINGES on the DOOR (V) to the HINGE BRACKETS on the RIGHT END (A). å...
- Page 26 Step Step 22 Refer to the enlarged diagram to identify the parts on the å Adjusting screw (horizontal) HINGES. Mounting screw (depth) The DOORS may need some adjustments. Follow the å text below to make needed adjustments. DOOR ADJUSTMENTS: å To adjust the DOORS from side to side (horizontal), turn the adjusting screw in or out.
- Page 27 Step Step 23 Apply the WARNING LABEL (25) to the å TOP (D). You should be able to read the label when the TV is removed from the unit. When the TV is in place, it should hide the label. Peel off the backing and apply the label as shown 50 lbs.
- Page 28 Step Step 24 Push the RUBBER SLEEVES (16) over the METAL PINS (15). Insert the METAL PINS into the hole locations of your å choice in the RIGHT END (A) and UPRIGHT (C). Set the ADJUSTABLE SHELF (H) onto the METAL PINS. To insert a drawer into your unit, line up the EXTENSION SLIDES on the drawer with the EXTENSION RAILS on the å...
- Page 29 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves or drawers. •...
