Product Overview

2.6.3 Immunity Requirements

2 2 The immunity requirements for frequency converters depend on the environment where they are installed. The
requirements for the industrial environment are higher than the requirements for the home and office environment. All
Danfoss frequency converters comply with the requirements for the industrial environment and consequently comply also
with the lower requirements for home and office environment with a large safety margin.
To document immunity against electrical interference from electrical phenomena, the following immunity tests have been
made on a system consisting of a frequency converter (with options if relevant), a screened control cable and a control box
with potentiometer, motor cable and motor.
The tests were performed in accordance with the following basic standards:
•
EN 61000-4-2 (IEC 61000-4-2): Electrostatic discharges (ESD): Simulation of electrostatic discharges from human
beings.
•
EN 61000-4-3 (IEC 61000-4-3): Incoming electromagnetic field radiation, amplitude modulated simulation of the
effects of radar and radio communication equipment as well as mobile communications equipment.
•
EN 61000-4-4 (IEC 61000-4-4): Burst transients: Simulation of interference brought about by switching a contactor,
relay or similar devices.
•
EN 61000-4-5 (IEC 61000-4-5): Surge transients: Simulation of transients brought about e.g. by lightning that strikes
near installations.
•
EN 61000-4-6 (IEC 61000-4-6): RF Common mode: Simulation of the effect from radio-transmission equipment
joined by connection cables.
See Table 2.12.
Voltage range: 380-480 V
Basic standard
Acceptance criterion
Line
Motor
Brake
Load sharing
Control wires
Standard bus
Relay wires
LCP cable
Enclosure
Table 2.12 EMC Immunity Form
1) Injection on cable shield
AD: Air Discharge
CD: Contact Discharge
CM: Common mode
DM: Differential mode
34
®
VLT AutomationDrive FC 360 Design Guide
Burst Surge
IEC 61000-4-4 IEC 61000-4-5
B B
2 kV/2 Ω DM
4 kV CM
4 kV/12 Ω CM
4 kV/2 Ω 1)
4 kV CM
4 kV CM 4 kV/2 Ω
1)
4 kV/2 Ω
4 kV CM 1)
2 kV/2 Ω
2 kV CM 1)
2 kV CM 2 kV/2 Ω
1)
2 kV CM 2 kV/2 Ω
1)
2 kV/2 Ω
2 kV CM 1)
— —
®
MG06B202 - VLT is a registered Danfoss trademark
ESD Radiated electromagnetic
IEC field
61000-4-2 IEC 61000-4-3
B A
— —
— —
— —
— —
— —
— —
— —
— —
8 kV AD
10 V/m
6 kV CD
RF common
mode voltage
IEC 61000-4-6
A
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
—
