Technical Information
JS2000 Joystick
Product specifications

Electrical characteristics

Environmental characteristics

© Danfoss | May 2017
Electrical
Sensor type
Resolution
Supply voltage range (Vs)
Over voltage, maximum
Reverse voltage, maximum
Output voltage range
X and XY, ± 40% span
Output voltage range
XYZ, ± 25% span
Output impedance
Center tap voltage (no load)
Center tap impedance
Return to center voltage (no load)
Current consumption
Output sense, XY axis
Output sense, Z axis
Environmental
Operating temperature
Storage temperature
Ingress Protection (IP) rating
EMC immunity level
EMC emissions level
ESD immunity level
Hall effect
Infinite
5 V DC ± 0.5 V DC, regulated
15 V DC
14.5 V DC
Nominal 0.5 to 4.5 V DC
Nominal 1.1 to 3.0 V DC
100 Ω each axis
50% Vs ± 1%
1.1 kΩ
X and Y axis—within ± 60 mV of Vs/2 at 20°C (68°F), ± 73 mV over full
temperature range
Z axis—within ± 100 mV of Vs/2 @ 20°C (68°F), ± 100 mV over full
temperature range
17.5 mA, nominal
The twin outputs of the XY axis can be independently selected to be rising
together in the same direction (PP) or opposed (PN).
The three axis option can only provide a single output per axis.
-25°C (-13°F) to 70°C (158°F)
-40°C (-40°F) to 70°C (158°F)
IP 65, above panel
60 V/m (25 MHz to 1 GHz, 1 kHz sine wave modulation)
Complies with EN50081-1 (1992), 30 MHz to 1 GHz
±8 kV Contact discharge; 15 kV air discharge (10 discharges)
520L0876 | BC00000073en-US0102 | 15
