Technical Information
JS2000 Joystick
Product installation
Dimensions and mounting
10 |
©
Danfoss | May 2017
Mounting dimensions in millimeters [inches]
K1 Grip
1
65.0
[2.559]
6.3
[0.248]
Forward
31.0
[1.22]
35.0
Ø3.5 [Dia 0.138]
[1.378]
in four places
35.0
[1.378]
2
Reverse
47.5
Right
Left
[1.87]
Forward
1
Optional boot protector supplied on K1 only
2
Flange dimension 44.3 [1.744] square (with trim plate removed)
4 off through holes Ø3.3 [Dia 0.13], countersunk on top surface
S Grip
S1 - S5 Grip
71.0
[2.795]
47.5 [1.87]
E Grip
E1 - E5 Grip
78.0
71.0
[3.071]
[2.795]
520L0876 | BC00000073en-US0102
78.0
[3.071]
kwa1392485256163
