Graf OPTIMAX Installation Instructions And Maintenance page 8

Installation instructions and maintenance for the
GRAF Optimax
®
Optimax -Industrial-Filter
external for green areas
(pedestrian weight re-
sistant)
Order- No. 340035
®
Optimax -Industrial-Filter
external for light traffic ar-
eas
Order No. 340036
The points described in these
instructions must be followed
correctly. If not correctly ob-
served, any right to claim on the
guarantee may be refused. For
all additional GARANTIA arti-
cles purchased there are sepa-
rate installation instructions en-
closed in the transportation
packing.
Any missing instructions must
be requested directly from us.
A complete check of the tank for
possible damage must be car-
ried out before the installation in
the excavation begins.
The installation must be carried
out by a professional firm.
®
-Industrial-Filter external
Contents
1.
General notes
1.1 Safety
1.2 Labelling/Tagging obligation
2.
Installation requirements
®
-Industrial-Filter - pedestrian
2.1 Optimax
weight resistant
®
-Industrial-Filter - light traffic resistant
2.2 Optimax
3.
Transport and storage
3.1 Transport
3.2 Storage
4.
Technical data
5.
Assembly / Installation of external
Filter
5.1 Preparation of the excavation
5.2 Placing in the excavation and laying
the connections
5.3 Telescope installation
5.4 Filling
5.5 Assembly of the extraction mechanism Page 10
6. Commissioning and Service
6.1 Commissioning
6.2 Service
Page 6 of 20
Page 7
Page 7
Page 8
Page 8
Page 9
Page 10
Page 10
