3.1

Transport

During the transport the filter must be well secured against slipping or falling. If the Filter is to
be secured for transportation with webbing straps, it is to be ensured that the filter remains
undamaged.
Stress and excess loading caused by impact are to be avoided. Under no circumstances is
the filter to be rolled or slid over the ground surface.
3.2

Storage

Any necessary temporary storage of the filter must be on an appropriate level surface without
sharp objects. During the storage it is important to avoid damage caused by the surrounding
environment or foreign objects.

3. Transport and storage

4. Technical data

Page 8 of 10
A -A
Ø 8 5 0 [3 3 ,5 ]
Ø 6 3 0 [2 4 ,8 ]
Page 8 of 20
1 1 8 0 [4 6 ,5 ]
8 5 0 [3 3 ,5 ]
Ø 8 5 0 [3 3 ,5 ]
Ø 6 0 0 [2 3 ,6 ]
D N 2 0 0
3 7 5 [1 4 ,8 ]
D N 1 6 0
5 7 0 [2 2 ,4 ]
A b la u f
1 1 8 0 [4 6 ,5 ]
Z u la u f
D N 1 6 0
T a n k
2 3 5 [9 ,3 ]
