15.12 Spare parts list indoor modules WKF 85/120/180

Nr. Designation
Smart BVT
From series:
Smart Serv
From series:
1 Front panel / cover
2a Cover monovalent / single energy source
2b Cover bivalent parallel
3 Control box
4 I/O module SMT
5 Control panel Smart-Control
6 Plate heat exchanger
7 Safety assembly
8 Actuator bypass valve
9 Valve body bypass valve
10 Auxillary heater 9 kW, 400V/3~/50 Hz
11 Actuator 3-way-valve
12 Valve body 3-way-valve
13 Ultrasonic flow rate meter
14 Primary pump indoor module
15 Actuator 3-way-valve bivalent operation
16 Valve body 3-way-valve bivalent operation
17 Terminal blocks
18 Pillar block pipe group
19 Control board Comkit
22 Ball valve for filling/drainage
23 Bleeder 1/4"
WKF 85 WKF 120
1266F 1268G
5001... 5001...
1266F 1268G
8001... 8001...
EDP number EDP number
1120901 1120901
1120902 1120902
1120902-1 1120902-1
1120915 1120915
1120650 1120650
248100 248100
1120940-1 1120940-1
1120010 1120010
1120913 1120913
1120913-1 1120913-1
260066 260066
1120912-3 1120912-3
1120912-2 1120912-2
1120914 1120914
1120911 1121304
1120912-3 1120912-3
1120912-2 1120912-2
1120922 1120922
1120904 1120904
252001 1120999
1120905 1120905
1120059 1120059
WKF 180
1270G
5001...
1270G
8001...
EDP number
1120901
1120902
1120902-1
1120915
1120650
248100
1120941-1
1120010
1120913
1120913-1
260066
1120912-3
1120912-2
1120914
1121304
1120912-3
1120912-2
1120922
1120904
1120999
1120905
1120059
