2.7 Unit dimensions outdoor module

A
Fig. 1: Unit dimensions outdoor module
Dimensions in mm
WKF/WKF-compact 85
WKF/WKF-compact 120
WKF/WKF-compact 180
WKF 120 Duo
WKF 180 Duo

2.8 Unit dimensions indoor modules

Unit dimensions indoor modules WKF 85/120/180
Fig. 2: Unit dimensions indoor modules series WKF 85/120/180 (all dimensions in mm)
B
A B
880 800
940 1010
940 1430
940 1010
940 1430
792
D
C
C D
310 660
330 620
330 620
330 620
330 620
500
E
E
346,5
360
350
360
350
17
