Spare Parts List Outdoor Module Wkf/Wkf-Compact 85 - REMKO WKF-compact Series Assembly And Operating Instructions Manual

15.2

Spare parts list outdoor module WKF/WKF-compact 85

Nr. Designation
From series:
1 Compressor
2 Laminated heat-exchanger
3 Four-way change over valve
4 Shut-off valves
5 Fan blade
6 Cover panel
7 Side panel, left
8 Front panel
9 Fan protection guard
10 Side panel, right
11 Side panel, right
12 Grille, rear
13 Fan motor
Evaporator sensor/
14
compressor set sensor
Hot gas sensor /
15
outdoor temperature set sensor
16 Transformer
17 Electronic expansion valve
18 Main board
19 Display
20 EMI board
When ordering spare parts, please state the computerised part no., device number and device type (see
type plate)!
WKF 85 WKF-compact 85
1267... 1267...
EDP-number EDP-number
1120310 1120310
1120311 1120311
1120312 1120312
1120313 1120313
1120314 1120314
1120315 1120315
1120316 1120316
1120317 1120317
1120318 1120318
1120319 1120319
1120320 1120320
1120321 1120321
1120322 1120322
1120323 1120323
1120324 1120324
1120325 1120325
1120326 1120326
1120327 1120327
1120328 1120328
1120329 1120329
WKF 85
WKF-compact 85
1293...
EDP-number
1120310
1120311
1120312
1120313
1120314
1120560
1120561
1120562
1120563
1120564
1120565
1120566
1120322
1120323
1120324
1120325
1120326
1120327
1120328
1120329
