REMKO WKF / WKF-compact
15.16 Spare parts list indoor modules WKF 120/180 Duo
No.
Designation
Smart Serv
From serial number:
1
Front panel / cover
2
Lid
3
Switching cabinet
4
I/O module SMT
5
Smart Control panel
6
Plate heat exchanger raw
6a
Plate heat exchanger soldered / isolated above
6b
Plate heat exchanger soldered / isolated down
7
Safety assembly
8
Bypass valve servo motor
9
Bypass valve valve body
10
Auxiliary heater 9 kW
13
Ultrasonic flow rate meter
14
Primary pump indoor module
17
Terminal strips
18
Pipe assembly support block
19
Com-Kit control board
22
Ball valve for filling/drainage
23
Bleeder, 1/4"
Spare parts not illustrated
Complete wiring harness, indoor unit
Smart Count (SD card) *)
Coding resistor, Master (upper I/0 module)
Coding resistor, Slave (lower I/0 module)
Transformer
*) When replacing the SD card always replace three cards and ordered according to 3 cards
When ordering spare parts, please always state the EDP number, unit number and unit type
(see name plate)!
106
WKF 120 Duo
WKF 180 Duo
1401F8000
EDP number
EDP number
1120901
1120902
1120915
1120650
248100
1120940
1120940-1
1120940-2
1120010
1120912-3
1120912-2
260066
1120914
1121304
1120922
1120904
1120999
1120905
1120059
1121055
260030
1121052
1121054
1120935
1300F8000
1120901
1120902
1120915
1120650
248100
1120941
1120941-1
1120941-2
1120010
1120912-3
1120912-2
260066
1120914
1121304
1120922
1120904
1120999
1120905
1120059
1121055
260030
1121053
1121054
1120935
