CA-6
• „connection failed", „no control panel signals", „poor quality of connection, no
control panel handshake"
− connection with the control panel was unsuccessful,
− the control panel picked up the phone but did not answer because the modem
signal was corrupted,
− the control panel went off-hook, but did not answer the modem signal, because it
was neither V.21 or BELL 103 transmission format (incompatible or wrongly
configured modem),
• „communication password not acknowledged" – the control panel established
connection, but the computer communication password does not correspond to the one
programmed in the control panel in FS3 function – the panel disconnects,
• „connection interrupted" – the control panel stopped answering the computer signals.
Note: If the control panel answers the call but fails to establish communication and
disconnects, while the "double call" option is deactivated, it will be answering no
calls for the next 5 minutes.

DLOAD10 program

The DLOAD10 program, delivered with the control panel, is designed for programming the
CA-5, CA-6, CA-10 control panels, as well as the RX-2K, RX-4K and RE-4K radio controllers,
the GSM-4 module and the ACU-100 wireless system controller, from the computer.
Additionally, the program makes it possible to create: documentation of alarm systems, sets
of programmed system parameters for various configurations ("patterns" which facilitate the
programming of new systems), event sets for each system. It also enables to remotely
operate the control panel in the same way as with the keypads.
The program is designed for IBM PC/AT compatible computers. It works in any computer
hardware configuration in the WINDOWS (9x/ME/2000) environment. It is recommended that
the program be installed on the computer hard disk.
The control panel communicates with the computer through the RS-232 port or via the
telephone line. For telephone communication with the panel, the program uses a modem
controlled by one of the COM ports (internal or external), compatible with the HAYES "AT
Command" standard. Communication with the control panel is possible in the CCITT V.21 or
BELL 103 standards (at 300 Bps). As the control panel transmits data only with a speed of
300 bauds, the modem must support this speed of operation.
Usually a suitable modem configuration is necessary: 300 bps speed and disabled
function of negotiating the transmission standard.
In order to install the program, run the D10setup.exe program from the floppy disk which is
delivered with the control panel. When installation is completed, you can start the program.
Access to the program is protected with an access code. After installation, the code is
[1][2][3][4] and can be changed to any sequence of 16 alphanumeric characters. As long as
it is set by default, you can start the program (with default code [1][2][3][4]) by pressing the
„ENTER" key (no access code need to be entered).
Having started the program, you should choose in the computer a proper configuration and
initialize the work of RS port or modem by means of which the control panel will be
programmed. By default, the program opens the CA-10 window. Than you can select the CA-
6 control panel and start the connection (either remote or local).
A HELP system, which facilitates operating of the DLOAD10 and programming of the control
panel parameters, is provided. The system is accessible from the „HELP" menu, or by
pressing the F1 key on the computer keyboard. To get an instant access to more detailed
information, first select the required element in the program window (by clicking on it with the
left mouse button), and then press the F1 key.
