Satel CA10 plus User Manual

Satel CA10 plus User Manual

Alarm control panel with led keypad software version 4.7
Hide thumbs Also See for CA10 plus:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
User Manual
Alarm Control Panel
CA10 plus
(software version 4.7)
with LED Keypad
GDAŃSK
ca10pldu_e 07/03
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA10 plus and is the answer not in the manual?

Questions and answers

Related Manuals for Satel CA10 plus

Summary of Contents for Satel CA10 plus

  • Page 1 User Manual Alarm Control Panel CA10 plus (software version 4.7) with LED Keypad GDAŃSK ca10pldu_e 07/03...
  • Page 2 (European Union Directives 91/157/EEC and 93/86/EEC). The SATEL Company recommends that operation of the whole alarm system be regularly tested. However, a reliable alarm system does not prevent burglary, assault or fire from happening, it only diminishes the risk that such a situation will cause no alarm or notification.

  • Page 3: Armed Modes

    CA10 plus with LED Keypad CA-10 plus Control Panel with a LED keypad The CA-10 plus control panel is a modern, microprocessor-based equipment designed for burglary and assault signaling systems. The CA-10 plus panel controls the alarm system, responds to information coming from the system detectors about an intrusion into the protected facility, and provides signaling and notification about the event.
  • Page 4 Instrukcja użytkownika SATEL Silent armed mode Armed mode in which alarms are signaled only in the panel keypads. The installer can decide which of the detectors are to be automatically by-passed on activating this mode; he can also choose signaling device to be used in that mode.
  • Page 5 CA10 plus with LED Keypad • four short and one long - successful completion of a user function, activation of type 13 output (BI switch), or activation of type 14 output (MONO switch). System events signaling: • continuous signal - alarm condition, •...
  • Page 6 Instrukcja użytkownika SATEL The panel may fail to arm the system if: • the panel is not ready for arming: there are specifically selected zones which cannot be violated when the system is being armed and one of them is violated at the time of arming - the panel will signal the situation with three long beeps.
  • Page 7 CA10 plus with LED Keypad System Status Telephone Messaging The owner of the facility where a CA-10 plus control panel is installed can check if there was an alarm in the system by using a telephone. In order to do so he has to call the protected facility: the control panel will answer the call and inform about the system status.
  • Page 8 Instrukcja użytkownika SATEL The control is effected by using the DTMF signals from the telephone keypad. In order to call a particular function, press in turn the telephone keys according to the calling procedure shown in the table. Signaling the partition state: •...

  • Page 9: Switching To N Partition (Go To N)

    CA10 plus with LED Keypad „HOLD DOWN” User Functions The functions are available to any user (without using the access code). They are activated by holding down the function key for about 3 seconds. SWITCHING TO n PARTITION (GO TO n) In the alarm systems divided into several partitions (subsystems), a single keypad control over the whole system is possible.

  • Page 10: Viewing Trouble Log

    Instrukcja użytkownika SATEL VIEWING TROUBLE LOG The function allows the panel user to reproduce information about the system trouble conditions from the panel memory log. On activating the function the LEDs ALARM and ARMED go on and the TROUBLE LED starts blinking. At the same time one of the LEDs 1 to 12 illuminates indicating the type of alarm.

  • Page 11: Switching Chime On/Off

    CA10 plus with LED Keypad - LED 2 – the battery voltage is too low (lower than 12V under load) – discharged battery. This state may last for several hours after the system has operated without the mains supply (or after a discharged battery is connected).

  • Page 12: Panic Alarm

    Instrukcja użytkownika SATEL message about auxiliary alarm to the monitoring station and activate telephone messaging. PANIC ALARM This function activates the panic alarm from the keypad. The keypad activated functions can be disabled by the installer. User functions If the control panel is not armed and is not signaling any alarm, users with an appropriate authority level can access several functions useful in everyday operation of the alarm system.
  • Page 13 CA10 plus with LED Keypad New User [CODE][ * ][2] This function is only available to the master user. It makes possible to add new users to a partition, assign an access code to them and determine their authority level.
  • Page 14 Instrukcja użytkownika SATEL Example: deleting the third user’s access code (master code = 1234) [1234] [ * ] - activating the „user function” mode by the master user, [3] - calling the „delete code” function, the zone LEDs indicate the partition users' numbers.
  • Page 15 CA10 plus with LED Keypad Activating MONO SWITCH Type Output [CODE][ * ][7] The purpose of the function will be determined by the installer. It can activate e.g. electric locks, bells, signal lamps, or any other devices. After calling the function, the control panel generates two short beeps and waits for the output number key (1-6) to be pressed.
  • Page 16 Instrukcja użytkownika SATEL Start Download [CODE][ * ][0] This function can be activated by the master user and the users with authority level 1. It starts the control panel - service PC telephone connection. The function enables the panel - PC telephone communication when the possibility to initiate connection from the PC computer is blocked.

  • Page 17: Technical Reliability Of The Alarm System

    CA10 plus with LED Keypad Technical Reliability of the Alarm System The alarm system consists of devices whose reliability is vital for the effectiveness of facility protection. The elements of the alarm system are exposed to various outside factors, for example, weather conditions (outdoor signaling devices), lightning (overhead telephone lines, power lines, outdoor signaling devices), mechanical damage (keypads, detectors, etc.).

  • Page 18: History Of The Manual Updates

    Instrukcja użytkownika SATEL History of the manual updates The updates below refer to the manual for the control panel with program version 4.1. Program Date Description of updates version A new section added: operation via a telephone of the control panel 08-2002 working with MST-1 telephone control module (see p.
  • Page 19 LEDs 1÷12 (zones state) - hold down for 3 sec. ON - zone violated to go to selected partition. OFF - zone OK - hold down for 3 sec. to fast blinking - zone activated alarm activate alarm log viewing on , short off every 2 sec.
