Alternate Firmware Label
The label of the alternate (previous) firmware
Alternate Firmware Date
The build date of the alternate (previous) firmware
Firmware Commands
Run Alternate Firmware
Return the card's firmware to the alternate (previous) version.
Firmware Update
Update the card's firmware to a new/different version.
Updating the Card Firmware
For description of the field and folders used when updating, see
page.
To update the firmware on the Unity card:
1. On a computer, download the latest Unity-card firmware from
us/support/software-download/monitoring/liebert-intellislot-communications-interface-cards/.
• If you know the card's IP address, type the IP address in a web browser.
• If you do not know the IP address, connect the card to a computer with an Ethernet cable
and open a web browser, see
page 4.
The card has an Ethernet RJ-45 connector on the front, see Figure 1.1 on page 1.
When directly connected, the card and computer automatically negotiate
communications, which takes about 1 minute. When communication is established, open a
web browser and enter the address 169.254.24.7, which is the card's default
Autoconfiguration IPv4 Address.
The card's Web UI will open.
2. On the Communications tab, select Support > Firmware Update in the tab menu on the left
panel.
3. Click Edit and enter the administrator user name and password.
4. Click Web.
The firmware-update screen opens.
5. Browse to the firmware file that was downloaded in
Firmware.
NOTE: Do not navigate away from the Firmware Update screen and do not close the browser once the
update begins. Either action will interrupt the download.
6 Editing the Unity Card Configuration
Firmware Update Folder
Connecting Directly to Computer for Configuration
Step 1 to update, select it, and click Update
on the previous
https://www.vertivco.com/en-
on
63
