The Sensor menu contains folders showing an overview of the installed sensors, the event status of the
sensors, download links for log files and sensor-configuration settings described in the following table.
Table 4.3 Sensor-tab menu folders
FOLDER
Summary
Active Events
Downloads
Sensor Server
• System Model Number
• System Status
• Too Many Sensors
• Slots Not Available
• Acknowledge Sensor
Changes
Sensor Change
Sensor Order

5.5.1 Sensor-tab Summary Page

The Sensor tab Summary Page shows the status of all installed sensors, details about selected sensor and
a Setting pane that permits changing a sensor's label, thresholds if applicable, alarm configuration and
acknowledging alarms and events. See Figure 4.2 on the previous page.
Selecting a sensor permits changing its settings at the lower part of the window.
Events may also be acknowledged on this window.

5.5.2 Sensor-tab Summary Details Pane

The Details pane of the Sensor tab appears when the Summary folder is selected. The area shows the
status of all connected sensors. See Figure 4.2 on the previous page.
Supported sensors include:
• Temperature
• Humidity
• Door Closure
• Contact Closure
• Leak Detection
5 Unity Card Web-page Layout
DESCRIPTION
Displays a list of currently discovered sensors, with their status and values. Also displays a
detail section about the sensor that is currently selected
Displays a list of sensor events that are currently active.
Displays a list of text files that can be downloaded. The files available are dependent on
the current state of the card.
Displays overall information about the sensors.
Lists events showing sensors that have been added or removed. If the list has any
entries, an Acknowledge button appears. Clicking the Acknowledge button clears the
list. The Acknowledge button on this page has the same behavior as the Acknowledge
button on the Sensor Server page.
Displays a list of sensors, and allows setting the order in which the sensors are displayed
on the Summary page.
