5.2 Help Text

Each Web page shown by the Unity card has informational text that is revealed by hovering the cursor
over the icon to the left of the Status, Events or Settings row.
The Web UI may display any of the 6 icons described in the following table.

5.3 Managed Device Tab Menus

Menus on the Managed Device tab list only data that is relevant to the monitored equipment. For
example, menus shown by a Unity card installed in a UPS differ from menus shown by a card installed in
Thermal Management equipment. Selected menu items also display detailed information based on the
equipment in which the card is installed. Power information is displayed in the Managed Device tab for a
UPS, while environmental information is displayed for a thermal-management unit.

5.4 Communications Tab Menu

The Communications tab shows the overall event status of the equipment and communication interface.
It contains logs of third-party information, communications settings, third-party protocol settings and
system status information as detailed in the following table.
5 Unity Card Web-page Layout
Table 4.1 Help text and icons
ICON DESCRIPTION
Event Normal
Event Information
Event Alarm
Event Warning
Event Critical
Tool Tip
