1 INTRODUCTION

This Liebert Unity platform delivers enhanced communication and control of AC Power, Power
Distribution and Thermal Management products. The platform communicates with Vertiv™ software tools
and services, including Trellis™, Trellis Power Insight, LIFE™ Services, Liebert SiteScan Web™ and Liebert
Nform™.
The platform includes the IS-Unity-DP™, IS-Unity-SNMP™, and IS-Unity-LIFE
Each card employs the Velocity Protocol to monitor and manage a wide range of operating parameters,
alarms, and notifications. The card communicates with Building Management Systems and Network
Management Systems via BACnet, Modbus, SNMP, LIFE/Remote Services, and YDN23 protocols.
Figure 1.1 IS-Unity-DP Card Features
ITEM DESCRIPTION
1 RJ-45 Ethernet port
2 Micro-USB port
3 Reset button, see Manually Resetting to Factory Defaults
4 RS-485 port (BACnet/MSTP, Modbus RTU or YDN23. Only one may be used.)
5 Liebert sensor-network port (SN sensors only)
™
cards.
on page 67.
