Generating a Self-signed SSL Certificate
1. On the Communications tab, select Configuration > Web Server > Certificate.
2. In the Settings section:
a. Click Edit.
b. In Generate Self-Signed SSL Certificate Mode, select the mode to use.
• If you select User Configured Settings, make entries in all of the configurable-value fields
(required), then click Save.
3. In the Commands section, click Enable, then click Generate next to Generate Self-Signed SSL
Certificate.
The generate dialog opens. See the following figure.
4. Follow the instructions in the dialog to generate and install the certificate.
Figure 5.3 Generate Self-Signed SSL Certificate dialog
™
6.4.6 LIFE Folder
The LIFE subfolder contains settings that affect use of the Vertiv™ LIFE Technology, a remote monitoring
and diagnostic service for Vertiv™ units. The LIFE settings are for use by trained Vertiv™ personnel only
and require no user changes. The following tables provide reference information about the LIFE settings.
Settings in this folder are managed by Vertiv™. A service contract is required.
For support, contact Vertiv™ Technical Support for LIFE Services at 1-800-435-7250, option 3.
Table 5.2 LIFE Status Settings
STATUS
Connection Media
Enable Date and Time
Settings
LIFE Technology
System Serial Number Override
6 Editing the Unity Card Configuration
DESCRIPTION
The LIFE Technology connection media
The date and time that LIFE Technology support was enabled.
Description
Enable or disable the LIFE Technology
When enabled, A user configured System Serial Number will override a Serial Number configured
in the device ,
