6.4 Configuration Folder

The top level Configuration folder displays the System Model Number of the Unity card. This name is
factory-set and cannot be changed. The Configuration folder contains the following subfolders:
•

System Folder

• Local Users Folder
• Remote Authentication Folder
• Network Folder
• Web Server Folder
• LIFE™ Folder
• Remote Services Folder
• Velocity Protocol Folder
• Messaging Folder
• Cloud Client Folder
6.4.1 System Folder
The System subfolder displays general information about the monitored and managed device. You can
select the temperature units displayed, which is "Celsius" by default.
To edit the information displayed:
1. Click Edit, and enter a user name and password if necessary.
2. Make the changes, and click Save.
Time Service Settings
The System subfolder contains the Time Service folder. Each setting offers a menu of choices or an
enable/disable check box.
Time Service setting options
External Time Source
The external source to use for time synchronization. Default = NTP Server.
Primary NTP Time Server
URL, Hostname, or IP address of the primary NTP time source. 64-character maximum.
Backup NTP Time Server
URL, Hostname, or IP address of the back-up NTP time source. 64-character maximum.
NTP Time Sync Rate
The rate at which time will be synchronized with the Network Time Protocol server, if NTP is the
external time source.
Time Zone
Time zone where the device is located.
