10.5.
DN Inch
40 1,5"
50 2"
2,5"
65
3"
80
100 4"
Double seat valve
DELTA DA3+ - ATEX
Instruction manual: UK - rev. 0
10. Technical Data
fig. 10.5.
open
valve position
Table to fig. 10.5. / Dimensions in mm
A B
6 3
11 10
15 16
21 16
27 16
31 21
50 21
valve position
C
stroke H1
C
upper shaft
21,2 32
21,2 39
21,2 45
21,2 45
21,2 45
36,2 50
36,2 50
UK
closed
upper
valve shaft
lower
valve shaft
stroke H1
lower shaft
26
33
39
39
39
44
44
16
