- Page 1 11.2018 New as of: CEREC camera Care, cleaning, disinfection and sterilization Instructions for CEREC Omnicam and CEREC Bluecam (valid for USA) English...
-
Page 2: Table Of Contents
Table of contents Dentsply Sirona Instructions for CEREC Omnicam and CEREC Bluecam Table of contents Cleaning agents ...................... CEREC Omnicam ....................General information ..................Components of the Omnicam ..............Removing the mirror sleeve ................. Refitting the mirror sleeve ................Mirror sleeve reprocessing overview ............ -
Page 3: Cleaning Agents
Dentsply Sirona 1 Cleaning agents Instructions for CEREC Omnicam and CEREC Bluecam Cleaning agents NOTE Use only chemical products recommended by Dentsply Sirona. Kerr Corporation ● CaviCide ● Cavi Wipes Patterson ● pdCARE ● pdCARE Wipes > 60% isopropyl alcohol 63 09 863 D3492 D3492.201.03.10.02 11.2018... -
Page 4: Cerec Omnicam
Instructions for CEREC Omnicam and CEREC Bluecam CEREC Omnicam CAUTION If the CEREC Omnicam accidentally falls down, check to make sure that the camera windows and coated sapphire glass are not damaged. If the CEREC Omnicam has been damaged, it must no longer be used on patients. -
Page 5: Components Of The Omnicam
Dentsply Sirona 2 CEREC Omnicam Instructions for CEREC Omnicam and CEREC Bluecam 2.2 Components of the Omnicam Components of the Omnicam Press detent to release Sapphire glass (coated) Mirror sleeve Camera windows Removing the mirror sleeve If required to remove the mirror sleeve do the following: 1. -
Page 6: Mirror Sleeve Reprocessing Overview
(wrapped). Pre-cleaning of the mirror sleeve Cleaning process immediately after using the CEREC Omnicam: While the mirror sleeve is attached to the camera, wipe off so that any surface contamination cannot harden and adhere to the surface of the mirror sleeve. -
Page 7: Disinfecting The Camera Body And Mirror Sleeve
2.7 Disinfecting the camera body and mirror sleeve Disinfecting the camera body and mirror sleeve NOTE Do not spray the CEREC Omnicam or immerse it in cleaning agents or disinfectants! ➢ Use a new cotton gauze moistened with one of the cleaning products listed in the „Cleaning agents ... - Page 8 2 CEREC Omnicam Dentsply Sirona 2.8 High-level disinfection of the mirror sleeve (with HLD Set) Instructions for CEREC Omnicam and CEREC Bluecam NOTE It is recommended that you never switch between disinfecting and sterilizing solutions. However if you do, make sure you thoroughly rinse the HLD set before switching.
- Page 9 Dentsply Sirona 2 CEREC Omnicam Instructions for CEREC Omnicam and CEREC Bluecam 2.8 High-level disinfection of the mirror sleeve (with HLD Set) 8. Cautiously fill the HLD container up to the marked level (B) per manufacturer´s instructions. A funnel can be used to assist with filling the liquid (A).
- Page 10 2 CEREC Omnicam Dentsply Sirona 2.8 High-level disinfection of the mirror sleeve (with HLD Set) Instructions for CEREC Omnicam and CEREC Bluecam 10. Place the lid on the container and leave the mirror sleeve at least 12 ® minutes for CIDEX OPA or 30 minutes for Sporox II in the disinfectant.
- Page 11 Dentsply Sirona 2 CEREC Omnicam Instructions for CEREC Omnicam and CEREC Bluecam 2.8 High-level disinfection of the mirror sleeve (with HLD Set) 13. Carefully and slowly remove the plug with the holder from the mirror sleeve by downward movement of the holder. Make sure that the mirror sleeve points upwards not to risk any damage by liquids entering the inside of the mirror sleeve.
-
Page 12: Dry Heat Sterilization Of The Mirror Sleeve
The process for dry heat sterilization is as follows: 1. Pre-cleaning (see „Pre-cleaning of the mirror sleeve [→ 6]“) 2. Remove the mirror sleeve from the CEREC Omnicam (see „Removing the mirror sleeve [→ 5]“). 3. Sterilize the mirror sleeve using dry heat at 190°C for 6 minutes (unwrapped) or 12 minutes (wrapped). -
Page 13: Use Of Cerec Omnicam Disposable Sleeves
Instructions for CEREC Omnicam and CEREC Bluecam 2.10 Use of CEREC Omnicam Disposable Sleeves Use of CEREC Omnicam Disposable Sleeves 2.10 The CEREC Omnicam can use disposable plastic sleeves to ensure maximum infection control. These are available with order number 66 32 264. NOTE... -
Page 14: Cerec Bluecam
3 CEREC Bluecam Dentsply Sirona 3.1 CEREC Bluecam without sapphire glass Instructions for CEREC Omnicam and CEREC Bluecam CEREC Bluecam CAUTION If the CEREC Bluecam accidentally falls down, check to make sure that the front lens and prism are not damaged. If the CEREC Bluecam has been damaged, it must no longer be used on patients. -
Page 15: Components Of The Cerec Bluecam Without Sapphire Glass
Dentsply Sirona 3 CEREC Bluecam Instructions for CEREC Omnicam and CEREC Bluecam 3.1 CEREC Bluecam without sapphire glass 3.1.2 Components of the CEREC Bluecam without sapphire glass Press detent to release Camera support 6 pcs., Order No. 5945360 Prismatic tube... -
Page 16: Refitting The Prismatic Tube
3 CEREC Bluecam Dentsply Sirona 3.1 CEREC Bluecam without sapphire glass Instructions for CEREC Omnicam and CEREC Bluecam 3.1.4 Refitting the prismatic tube NOTE Do not use CEREC 2 / CEREC 3 prismatic tubes. NOTE Risk of damaging the front lens or prism. -
Page 17: Pre-Cleaning Of The Prismatic Tube
3.1.7 Disinfecting the camera body NOTE Do not spray the CEREC Omnicam or immerse it in cleaning agents or disinfectants! ➢ Use a new cotton gauze moistened with one of the cleaning products listed in the „Cleaning agents [→ 3]“ section. Wipe the camera body first and then the prismatic tube. - Page 18 3 CEREC Bluecam Dentsply Sirona 3.1 CEREC Bluecam without sapphire glass Instructions for CEREC Omnicam and CEREC Bluecam 6. Cautiously fill the HLD container up to the 40ml marked („Bluecam“ mark) level per manufacturer´s instructions. A funnel can be used to assist with filling the liquid.
-
Page 19: Dry Heat Sterilization Of The Prismatic Tube Without Sapphire Glass
Dentsply Sirona 3 CEREC Bluecam Instructions for CEREC Omnicam and CEREC Bluecam 3.2 CEREC Bluecam with sapphire glass 3.1.9 Dry heat sterilization of the prismatic tube without sapphire glass NOTE Dry heat sterilization and high-level disinfection must not be combined. -
Page 20: Components Of The Cerec Bluecam With Sapphire Glass
3 CEREC Bluecam Dentsply Sirona 3.2 CEREC Bluecam with sapphire glass Instructions for CEREC Omnicam and CEREC Bluecam 3.2.2 Components of the CEREC Bluecam with sapphire glass Press detent to release Camera support 6 pcs., Order No. 5945360 Prismatic tube... -
Page 21: Refitting The Prismatic Tube
Dentsply Sirona 3 CEREC Bluecam Instructions for CEREC Omnicam and CEREC Bluecam 3.2 CEREC Bluecam with sapphire glass 3.2.4 Refitting the prismatic tube NOTE Do not use CEREC 2 / CEREC 3 prismatic tubes. NOTE Risk of damaging the front lens or prism. -
Page 22: Pre-Cleaning Of The Prismatic Tube
3.2.7 Disinfecting the camera body NOTE Do not spray the CEREC Omnicam or immerse it in cleaning agents or disinfectants! ➢ Use a new cotton gauze moistened with one of the cleaning products listed in the „Cleaning agents [→ 3]“ section. Wipe the camera body first and then the prismatic tube. - Page 23 Dentsply Sirona 3 CEREC Bluecam Instructions for CEREC Omnicam and CEREC Bluecam 3.2 CEREC Bluecam with sapphire glass 6. Cautiously fill the HLD container up to the 40ml marked („Bluecam“ mark) level per manufacturer´s instructions. A funnel can be used to assist with filling the liquid.
- Page 24 We reserve the right to make any alterations which may be required due to technical improvements. © Sirona Dental Systems GmbH Sprache: englisch Printed in Germany D3492.201.03.10.02 11.2018 Ä.-Nr.: 126 041 Sirona Dental Systems GmbH 63 09 863 D3492 Fabrikstr. 31 Order No ...
