Figure 3-1:
A.
B.
C.
D.
3.2
Wire power and outputs in a HART single-loop
environment
CAUTION!
Meter installation and wiring should be performed by suitably trained personnel only in
accordance with the applicable code of practice.
Procedure
Wire to the appropriate power and output terminals and pins (see
Installation Manual
Transmitter outputs
Channel A (4-20 mA + HART)
Channel B (4-20 mA)
Channel C (RS-485)
Power terminals
Wiring
Figure
3-2).
21
