Emerson Micro Motion ELITE Installation Manual

Coriolis flow and density sensors
Hide thumbs Also See for Micro Motion ELITE:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Installation Manual
P/N 20002158, Rev. DA
June 2009
Micro Motion® ELITE®
Coriolis Flow and Density Sensors
Planning
Mounting
Wiring
Grounding

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micro Motion ELITE and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson Micro Motion ELITE

Summary of Contents for Emerson Micro Motion ELITE

  • Page 1 Installation Manual P/N 20002158, Rev. DA June 2009 Micro Motion® ELITE® Coriolis Flow and Density Sensors Planning Mounting Wiring Grounding...
  • Page 2 ©Copyright 2009, Micro Motion, Inc. All rights reserved. ELITE and ProLink are registered trademarks, and MVD and MVD Direct Connect are trademarks of Micro Motion, Inc., Boulder, Colorado. Micro Motion is a registered trade name of Micro Motion, Inc., Boulder, Colorado. The Micro Motion and Emerson...

  • Page 3: Installation Checklist

    Planning Installation Checklist q Make sure that the hazardous area specified on the sensor approval tag is suitable for the environment in which the sensor is installed. q Verify that the local ambient and process temperatures are within the limits of the sensor. See Environmental Limits. q If your sensor has an integral transmitter, no wiring is required between the sensor and transmitter.

  • Page 4: Best Practices

    • When transporting or lifting large sensors, it may be useful to identify the sensor’s center of gravity, shown in Figure 1. Refer to the Product Data Sheet for exact center-of-gravity specifications. Micro Motion ELITE Coriolis Flow and Density Sensors...

  • Page 5: Environmental Limits

    Planning Figure 1 Center of Gravity for Large Meters Approximate center of gravity Environmental Limits The ambient and process temperature limits of the sensor are shown in the following figures. • For all ELITE sensor models except high-temperature and extreme-high-temperature models, see Figure 2. •...
  • Page 6 • For the purposes of selecting electronics options, this graph should be used only as a general guide. If your process conditions are close to the gray areas, it may be inappropriate to use electronics options other than a junction box. Consult with your Micro Motion representative. Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 7 Planning Figure 3 Environmental Limits for High-Temperature Sensors Notes • When ambient temperature is below –40 °F (–40 °C), a core processor or Model 2400S transmitter must be heated to bring its local ambient temperature to between –40 °F (–40 °C) and +140 °F (+60 °C). Long-term storage of electronics at ambient temperatures below –40 °F (–40 °C) is not recommended.

  • Page 8: Mounting Elite Sensor

    Do not lift the sensor by the electronics or purge connections. Lifting the sensor by the electronics or purge connections can damage the device. Micro Motion ELITE Coriolis Flow and Density Sensors...

  • Page 9: Mounting A Cmf010 Sensor To A Wall Or Pole

    Mounting Mounting a CMF010 Sensor to a Wall or Pole The CMF010 sensor has an optional mounting configuration for use with small or flexible pipeline. If the pipeline adequately supports the sensor, this procedure can be skipped. Procedure Locate the optional mounting holes. For sensors with a junction box, the junction box must be rotated to the side to expose the mounting holes.

  • Page 10: Securing Wafer-Style Process Connections

    Slip the sensor alignment rings over each end of the sensor wafer, then insert the sensor between the process connections in the pipeline. See Figure 7. Micro Motion recommends installing gaskets (user-supplied). Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 11 Mounting Figure 7 Wafer-Style Connection Components Sensor wafer Flange bolt Alignment ring Flange nut Gasket (user-supplied) Insert the flange bolts through both process connections, and thread the flange nuts onto the bolts. With your fingers, tighten the flange nuts. Rotate the sensor alignment rings in the direction that pushes the bolts outward. See Figure 8. Rotate both rings until the assembly is centered and tight.

  • Page 12: Mounting Electronics Of High-Temperature Sensors

    The electronics of high-temperature ELITE sensors are attached to the end of a 32² (812 mm) pre-installed flexible conduit. The electronics must be separately mounted on a wall or instrument pole. The components of high-temperature sensor electronics are shown in Figure 9. Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 13 Mounting Figure 9 Components of a High-Temperature ELITE Sensor Electronics (Model 2400S transmitter shown) Mounting bracket Flexible conduit Sensor Procedure • For wall mounting, use the four supplied 5/16² (M8) bolts to secure the mounting bracket. See Figure 10. Installation Manual...
  • Page 14 Wall or flat surface Electronics (Model 2400S transmitter shown) Flexible conduit • For mounting to an instrument pole, use two user-supplied 5/16² (8 mm) U-bolts to secure the mounting bracket. See Figure 11. Micro Motion ELITE Coriolis Flow and Density Sensors...

  • Page 15: Attaching Extended Electronics

    Mounting Figure 11 Pole-Mount Components Instrument pole Electronics (Model 2400S transmitter shown) Flexible conduit Attaching Extended Electronics If you ordered a sensor with extended electronics, you will need to install the extender onto the sensor case. Note Extended core processors are matched at the factory to specific sensors. Keep each core processor together with the sensor with which it was shipped.
  • Page 16 Fit the extender onto the feedthrough by carefully aligning the notches on the bottom of the extender with the notches on the feedthrough. Close the clamping ring and tighten the clamping screw to 13–18 in-lbs. (1,5–2 N-m). Micro Motion ELITE Coriolis Flow and Density Sensors...

  • Page 17: Wiring Options

    Wiring Wiring Options The wiring procedure you follow depends on which electronics option you have. Wiring options are outlined in Table 3. Table 3 Wiring Procedures by Electronics Option Electronics Option Wiring Procedure Integral transmitter No wiring required between sensor and transmitter. See the transmitter installation manual for wiring the power and signal cable to the transmitter.

  • Page 18: Making A 4-Wire Connection

    Wiring Making a 4-Wire Connection Step 1: Cable Preparation Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 19 Wiring Step 2: Shield Termination Installation Manual...

  • Page 20: Making A 9-Wire Connection

    Ensure integrity of gaskets, then tightly close and seal the junction box cover and all housing covers on the transmitter or core processor. Refer to the transmitter installation manual for signal and power wiring instructions. Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 21 Grounding The sensor must be grounded. You can ground the sensor via the piping if the joints in the pipeline are ground-bonded. If the sensor is not grounded via the piping, connect a ground wire to the internal or external grounding screw, which is located on the transmitter, core processor, or junction box.

  • Page 22: Supplementary Information

    Make sure that there is a tight seal between the inlet connection and sensor case, so that air cannot be drawn by suction into the case or purge line during the purging process. Micro Motion ELITE Coriolis Flow and Density Sensors...

  • Page 23: About Rupture Disks

    Supplementary Information Run purge gas through the sensor. The purge time is the amount of time required for full exchange of atmosphere to inert gas. The larger the line size, the greater amount of time is required to purge the case. See Table 4. If purge lines are being used, increase the purge time to fill the additional volume of the purge line.
  • Page 24 90.9 84.2 79.5 74.2 71.4 68.5 67.3 Form B2 & D neck EN 1092-1 PN40 C-22 40.0 34.4 30.8 28.0 26.0 24.1 23.0 22.0 21.4 32/02 Form B1 collar/ 304 flange joint Micro Motion ELITE Coriolis Flow and Density Sensors...
  • Page 26 T +65 6777–8211 F +31 (0) 318 495 556 F +65 6770–8003 Micro Motion United Kingdom Micro Motion Japan Emerson Process Management Emerson Process Management Limited Horsfield Way 1–2–5, Higashi Shinagawa Bredbury Industrial Estate Shinagawa-ku Stockport SK6 2SU U.K. Tokyo 140–0002 Japan T +44 0870 240 1978 T +81 3 5769–6803...
