4

Installation and starting up

4.1 Calorimeter C 200

4.2 Installation

All the connections for draining as well as the peripherals are on the back of the
appliance.
Œ
Connect the calorimeter to the plug (4-pin plug
Check that the voltage information on the rating plate of the power supply unit matches
your mains supply.
Connect the power line of the plug to the voltage source.

12
measuring cell cover
tank fillers
display
keyboard
fill level display
Connecting the plug
PC connector
printer connector
ON/OFF switch
plug connector
Connecting peripherals
When connecting peripherals make sure that both they and the calorimeter are
switched off at ON/OFF switch
).
.
plug
IKA -WERKE C 200 Ver. 02/2.06
®
