Steelcase Tableau-Run-offs Assembly Directions page 4

5.
Slide the run-off so it is flush with the existing unit (Fig. 1). Make sure the
the steel mending bracket already installed on the existing unit (Fig. 2).
NOTE: Attachment screws at modesty panel are not required when unit fits up to a power
pedestal.
Fig. 1
6.
Now locate the fasteners installed in step 4, on page 3. There are two (2) screw dowels
located on the end of the modesty panel. These must fit into the fasteners which are
located on the end panel. Once the dowels are engaged with the fasteners, tighten them
securely by turning the fitting screw clockwise with a Philips head screwdriver.
DOWEL
MODESTY PANEL
Page 4 of 15
END PANEL
Steelcase
Fig. 2
FITTING
SCREW
MODESTY PANEL
run-off is resting upon
END PANEL
Y9501889
