5a.
Below is a top view of what the correct assembly should look like for installation of a filler
panel to a unit with an end panel.
End Panel
6.
Secure the plate to the run-off by using eight
(8) #8 pan head wood screws 1" long.
Page 11 of 15
Steelcase
Forward Position
Filler Panel
Modesty Panel
Y9501889
