Steelcase Tableau-Run-offs Assembly Directions page 13

2.
To attach filler panel to modesty panel use six (6) #8 pan head wood screws 1/2" long. Attach
three (3) brackets onto backside of filler panel, flush with outside edge of filler panel in
approximate location shown using six (6) #8 pan head wood screws 1/2" long.
attaching with a pedestal, use the back position holes.
3.
Slide the run-off so it is flush with the existing unit (Fig. 1). Make sure the
the steel mending bracket already installed on the existing unit (Fig. 2).
Fig. 1
Page 13 of 15
Fig. 2
Steelcase
NOTE: When
run-off is resting upon
Y9501889
