R e c o m m e n d e d I M S P o w e r S u p p l i e s
I P 8 0 6 / I P 8 0 6 - 2 4 0 †
U n r e g u l a t e d L i n e a r S u p p l y
Input 120 VAC Version .................................... 102-132 VAC
240 VAC Version .................................... 204-264 VAC
No Load Output Voltage* ............................... 76 VDC @ 0 Amps
Continuous Output Rating* ........................... 68 VDC @ 3 Amps
Peak Output Rating* ......................................... 64 VDC @ 6 Amps
* Measurements taken at 25°C, 120 VAC, 60 Hz.
† Optional 240 VAC Version
R e c o m m e n d e d I M S M o t o r s
IMS stocks the following 1.8° hybrid stepping motors that are recom-
mended for the IB1010 All IMS motors are CE marked. For more
detailed information on these motors please see the IMS catalog or web
site at www.imshome.com.
Single Shaft
M2-3450-S .................................................................... M2-3450-D
Single Shaft
M2-4247-S .................................................................... M2-4247-D
M2-4270-S .................................................................... M2-4270-D
M2-4288-S .................................................................... M2-4288-D
Range
34 Frame Motors
Double Shaft
42 Frame Motors
Double Shaft
61
