The motors are available in 3 stack sizes, single or double shaft, with or
without encoders. They handle currents up to 3 Amps in series or 6
Amps parallel, and holding torque ranges from 95 oz-in to 230 oz-in (67
N-cm to 162 N-cm).
These CE rated motors are ideal for applications where higher torque is
required.
Single Shaft
MH-2218-S .................................................................. MH-2218-D
MH-2222-S .................................................................. MH-2222-D
MH-2231-S .................................................................. MH-2231-D
O p t i o n s a n d A c c e s s o r i e s
See appendices for descriptions and technical data on these accessories.
Thermal Isolating Pad .................................................... TI-463
Thermal Non-Isolating Pad ......................................... TN-463
Heat Sink ............................................................................ H-4X
Interface Board ............................................................... OPT-140
Plug-on Screw Terminal Set ............................................. TS-6
23 Frame High Torque Motors
Double Shaft
47
