T T L I n t e r f a c e
+5VDC
1N916
CONTROLLER
OR EQUIV
OUTPUT
TTL INTERFACE
INTERFACE SHOWN CONNECTED TO
THE ENABLE INPUT, MAY BE USED FOR
THE OTHER LOGIC INPUTS
Figure 1.5.3: TTL Interface
O p e n C o l l e c t o r I n t e r f a c e
+VDC
R
¼ W
CONTROLLER
OUTPUT
OPEN COLLECTOR
INTERFACE
INTERFACE SHOWN CONNECTED TO
THE ENABLE INPUT, MAY BE USED FOR
THE OTHER LOGIC INPUTS
Figure 1.5.4: Open Collector Interface
430Ω
.
PIN 1
ENABLE
LOGIC
GROUND
H /F
STEP
CLOCK
CW /CCW
CURRENT
ADJUST
+VDC R
5 430
10 1200
12 1500
15 2000
24 3000
PIN 1
ENABLE
LOGIC
GROUND
H /F
STEP
CLOCK
CW /CCW
CURRENT
ADJUST
B Y J A D R A W N
PHASE A
PHASE A
PHASE B
PHASE B
V+
GROUND
D R A W N B Y J A
PHASE A
PHASE A
PHASE B
PHASE B
V+
GROUND
