R e c o m m e n d e d I M S M o t o r s
IMS stocks the following 1.8° hybrid stepping motors that are recom-
mended for the IB104. All IMS motors are CE marked. For more detailed
information on these motors please see the IMS catalog or web site at
www.imshome.com.
Single Shaft
M2-2215-S .................................................................... M2-2215-D
M2-2220-S .................................................................... M2-2220-D
M2-2232-S .................................................................... M2-2232-D
M2-2240-S .................................................................... M2-2240-D
Single Shaft
M2-3424-S .................................................................... M2-3424-D
M2-3437-S .................................................................... M2-3437-D
IMS also carries a new series of 23 frame enhanced stepping motors that are
recommended for use with the IB104. These motors use a unique relationship
between the rotor and stator to generate more torque per frame size while ensuring
more precise positioning and increased accuracy.
The special design allows the motors to provide higher torque than standard
stepping motors while maintaining a steadier torque and reducing torque drop-off.
The motors are available in 3 stack sizes, single or double shaft, with or without
encoders. They handle currents up to 3 Amps in series or 6 Amps parallel, and
holding torque ranges from 95 oz-in to 230 oz-in (67 N-cm to 162 N-cm).
These CE rated motors are ideal for applications where higher torque is required.
Single Shaft
MH-2218-S .................................................................. MH-2218-D
MH-2222-S .................................................................. MH-2222-D
MH-2231-S .................................................................. MH-2231-D
O p t i o n s a n d A c c e s s o r i e s
See appendices for descriptions and technical data on these accessories.
Thermal Isolating Pad .................................................... TI-100
Thermal Non-Isolating Pad ......................................... TN-100
Heat Sink ........................................................................... H-100
Interface Board ............................................................... OPT-140
Plug-on Screw Terminal Set ............................................. TS-6
52
23 Frame Motors
34 Frame Motors
23 Frame High Torque Motors
Double Shaft
Double Shaft
Double Shaft
