OneX Overview
Table 4
Fiber-Optic Port Cabling Specifications
SFP Module
10GBASE-SR
Installation Notes for the Cisco TwinGig and OneX Converter Modules
6
Table 3
Supported SFP+ Modules and Patch Cords (continued)
SFP+ Module Number Description
SFP-H10GB-CU3M Twinax cable assembly, 3m, 30 AWG
SFP-H10GB-CU5M Twinax cable assembly, 5m, 24 AWG
Table 4
lists the fiber-optic cabling specifications for the SFP+ modules that you
install in the converter module. Each port must match the wavelength
specifications on the other end of the cable, and the cable must not exceed the
stipulated cable length. The SFP modules using fiber-optic connections need
fiber-optic cables with LC/PC or LC/UPC connectors.
Wavelength
Fiber
(nanometers)
Type
850
MMF
Modal
Core Size
Bandwidth
(micron)
(MHz/km)
62.5
160
62.5
200
50
400
50
500
50
2000
Cable Distance
85 feet (26 m)
108 feet (33 m)
216 feet (66 m)
269 feet (82 m)
984 feet (300 m)
78-17572-04
