Removing a Converter Module

Step 1
Step 2
Step 3
Step 4
Step 5
78-17572-04
Figure 3
Installing a TwinGig Converter Module (Catalyst 3750-E
Specific)
1
Module inserted face up
2
Module inserted face down
To remove a converter module from the switch module slot, follow these steps:
Attach an ESD-preventive wrist strap to your wrist and to a bare metal surface on
the chassis.
Disconnect the cables from the SFP or SFP + module and remove the SFP or SFP+
modules from the converter module. (See the
SFP+ Modules" section on page
Pinch the latch arms on each side of the converter module, and carefully slide it
out of the slot
(Figure
Place all SFP or SFP+ modules and converter modules in an antistatic bag or other
protective environment.
Replace the EMI plug in the switch empty 10-Gigabit Ethernet module slot.
Installation Notes for the Cisco TwinGig and OneX Converter Modules
1
4 5
4 6
4 7
4 8
t 3 7 5 0 -
E
S E R IE S
P o E - 4 8
2
12).
4).
Converter Module Installation
4 7 X
4 9
X 2 -1
5 0
X 2 -2
5 1
4 8 X
5 2
"Installing and Removing SFP or
