Mocka Nava Buffet Assembly Instructions Manual page 8

Nava Buffet
Assembly Instructions
13
E
K
M M
L
Attach 2x hinges (L) to panel [13] using 4x screws (M), and attach 1x
seal (K) and secure with 1x screw (E). Attach 2x hinges (L) to panel
[14] using 4x screws (M). Now attach 1x seal (K) and secure with 1x
screw (E).
mocka.co.nz | mocka.com.au
M
M
L
M
M
L
13
E
K
M M
14
L
14
13
Attach door hinges on panels [13] and [14] to the unit using 16x screws
(M). Tighten with a screwdriver. Ensure the doors open and close easily.
NOTE: If the doors are uneven or
there is a gap in the middle, loosen
or tighten the screw on the door
hinge until they are sitting flush.
M
14
M
M
M
M
M
8
