Mocka Nava Buffet Assembly Instructions Manual page 10

Nava Buffet
Assembly Instructions
17
4
F
2
Insert 8x shelf plugs (F) into the unit at the desired height for the
shelves and rest the shelf panels [6] onto them. Ensure the shelves
are balanced and stable. Insert the three assembled drawers,
ensuring they slide along the rails smoothly.
mocka.co.nz | mocka.com.au
3
F
F
6
6
18
strap
A1
B1
Attach 12x wedges (A1) to the back of the unit as shown, and secure
with 12x screws (B1). Now attach 1x safety strap (V) to the back edge of
panel [1] using 1x washer (Z) and 1x screw (W). Tighten with a
screwdriver.
A1
B1
A1
B1
V
A1
B1
Z
W
A1
A1
B1
B1
10
