Mocka Nava Buffet Assembly Instructions Manual page 7

Nava Buffet
Assembly Instructions
11
Ensure slot in
nut is facing
incoming bolt.
O
O
N
11
N
Attach panels [10] and [11] together as shown using 4x nuts (O) and 4x
bolts (N).Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
N
O
O
O
10
10
12
P
N
U
11
P
N
Attach panels [10] and [11] to panel [8] using 10x screws (P). Attach
support leg [12] to panel [8] as shown. Screw the height adjuster (H) onto
the support leg [12]. Attach 4x plastic glides (U) to the legs using a
hammer.
P
H
12
P
P
8
P
P
U
U
P
P
U
P
7
