Nava Buffet
Assembly Instructions
1
E
E
I
E
E
E
E
I
4
Attach 1x bracket (I) to panel [4] using 2x screws (E). Attach 1x bracket
(I) to panel [5] using 2x screws (E). Tighten with a screwdriver. Cover
each bracket with 1x clip (J) as shown.
mocka.co.nz | mocka.com.au
J
I
5
2
C
Insert 2x bolts (C) into panel [4]. Insert 2x bolts (C) into panel [5].
C
4
C
C
5
2
