Kit Overview (3/7)
XMC™ LED Current Control Explorer Card
›
Header
Connectors
Voltage Divider for
Comparator Reference
Copyright © Infineon Technologies AG 2016. All rights reserved.
BSS306N (OptiMOS™)
24V DC
Input Jack
0-30V DC
Input Jack
Output jack
to LED engine
BAS3010A-03W
(Schottky Diode)
6
