Summary of Contents for aFe Power Scorcher

  • Page 1 Getting Started...

  • Page 2: Table Of Contents

    Questions and Answers ....26 Limited Warranty ......28 Down, Decrease Service .........29 Satisfaction Guarantee ....30 Copyright 2011 advanced FLOW engineering, Inc. Jeep is a registered trademark of Chrysler LLC. aFe Power, Inc. is not affi liated with Chrysler LLC. PAGE 2...

  • Page 3: Dear Auto Enthusiast

    User Guide. Note: aFe Power tuning devices for diesel engines are not currently compliant with CARB emissions certifi cation procedures but are in a “pending” status and will be completed as requirements are met. Therefore, they are presently not legal for sale or use in California on pollution controlled diesel-fueled vehicles.

  • Page 4: Getting Started - Step 1

    Getting Started - Step 1 Update Your Programmer Helpful Hint Regularly use the aFe internet update software to check Use the internet Easy for updates. The software can be downloaded at Update software to www.afepower.com. With the click of a mouse, your program- enable advanced mer is up-to-date with the latest software and calibrations.

  • Page 5: Getting Started - Step 2

    Do not remove the programming cable during any programming sequence. If you do, the vehicle may not start. A Scorcher programmer is designed to automatically go into Vehicle Recovery Mode and if this occurs, it will return your vehicle to factory stock. Contact Tech Support for assistance at 951.493.7155.

  • Page 6: Getting Started - Step 3

    Getting Started - Step 3 Program Your Vehicle Your programmer will automatically power on when it’s plugged into an OBD-II port. Select Tune Vehicle Helpful Hint Press OK “Quick Tune” changes the power level of your vehicle and uses the most popular features Select Quick Tune or Advanced Tune and settings.
  • Page 7 The Stock File is now saved (fi rst time only) - Press OK Select Tune Level - Follow on screen prompts for power level requirements. These may vary by product and could include all or some of the following: aFe Performance aFe Heavy Load Tow aFe Light load Tow aFe Transmission Only...

  • Page 8: Tunes

    Light Load Tow Optimizes engine and transmission performance for mid-weight range towing applications. Tow rated up to aFe Power recommended tow limits. See limits for your vehicle displayed by the programmer during programming process. Octane requirements vary for gas vehicles. Follow recommended guidelines.
  • Page 9 Engine and transmission calibrations are not installed. Only selected user options will be installed. aFe Factory Stock Returns vehicle to factory stock. Removes all Scorcher tuning from your vehicle. Recommended for trips to service centers for maintenance. aFe Transmission Only Optimizes transmission performance for towing applications.

  • Page 10: Advanced Options

    Tune to independently set options. Options vary by vehicle. aFe Speed Limiter Helpful Hint Adjusts top speed limiter by increments or fi xed values. Your Scorcher programmer i• Vehicle must have appropriate speed rated tires. is designed to automatically show you the advanced options Do not exceed proper operating conditions.
  • Page 11 Axle (Gear) Ratio Corrects the speedometer, odometer and automatic transmission shift points (where supported) for rear end gear changes. Confi rm aftermarket parts are installed before adjusting this option. 2007 – 2010 Wrangler JK gear ranges are 2.00 – 10.00 in 0.01 increments. Automatic Transmission Shift Points Adjust transmission points for optimized drivability and operation.

  • Page 12: Jeep

    Features ® Most Jeep options are optimized using the quick tuning option. Use Advanced Features to independently set options. Scorcher will automatically show you the advanced features available for your Jeep. Transfer Case (gear) Corrects speedometer, odometer and automatic shift points (where supported) for transfer case gear changes.
  • Page 13 The idle up is a real-time feature meaning no programming required. Just plug Scorcher into the OBD-II port and control the idle in real-time. The range you may increase the idle is 800 – 1600 RPMs.

  • Page 14: Jeep Power Levels

    Jeep Power Levels There are several available tunes in the Scorcher for Jeep vehicles. Scorcher automatically shows you the tunes available for your Jeep. 93 Performance Requires the use of 93 Octane gas and is used for maximum horsepower, torque and drivability for on-road and off-road uses.
  • Page 15 This tune is safe to use in 4WD-HI or 4WD-LO and is available for all Jeeps covered by aFe Power. Crawling Tune Is an aFe Power exclusive tune offering low throttle response and high low-end torque tune designed for precision low-speed maneuvers. This tune is currently only available for JK models.

  • Page 16: Returning To Stock

    The service center might reprogram your vehicle with an updated program without your knowledge. If you did not use an aFe Power programmer to return your vehicle to factory stock and your vehicle is reprogrammed by the service center, the programmer will no longer be able to program your vehicle.

  • Page 17: Engine Diagnostic Tool

    Use the Engine Diagnostic Tool to check trouble codes. A Diagnostic Trouble Code (DTC) arises when a vehicle’s computer detects a sensor failure or a parameter outside a specifi c range. Most vehicles will illuminate the check engine light. A Scorcher programmer will read, identify and let you clear DTCs if desired.

  • Page 18: Information And Settings

    (car database, gas truck database, diesel database, etc.) Firmware and databases are updated through the Scorcher Internet Easy Update application. Vehicle information Displays VIN of the programmed vehicle, programmer status and the Scorcher fi le number associated with the programmed vehicle. Display Settings Adjusts display settings for use in direct sunlight, nighttime or low lighting.

  • Page 19: Data Acquisition

    Also, with our advanced features, you can monitor and record individual live sensor values or computer data. Features available for your vehicle will automatically be shown once Scorcher has identifi ed your vehicle. DAQ 1: Data Logging Helpful Hint •...

  • Page 20: Scorcher Features

    Scorcher Features Here are the many exciting features of aFe Power products. Towing Power Speedometer Calibration Optimizes for handling heavy loads. Corrects speedometer, odometer and automatic transmission shift points (where Track Speed supported) for wheel, tire and rear end gear changes.

  • Page 21: Scorcher Mileage Features

    10. Some vehicles that recommend 89 or 91 that turn on your check engine light. octane may be able to use 87 octane after programming with aFe Power Scorcher providing additional savings at the pump Upgradable Your programmer can have even more features and calibrations added to it (additional costs may apply).

  • Page 22: Storage And Maintenance

    Storage and Maintenance It is NOT recommended to store your programmer in your vehicle in extreme heat, direct sunlight or extreme cold (temperatures near or below freezing). These conditions can cause malfunction or damage to the programmer. Pay attention to your programmer during vehicle programming. A status screen or prompt may require action or attention.

  • Page 23: Trouble Shooting

    If it does, then the wiring on the vehicle you are trying to program may be the issue (See your dealer for service). My vehicle has been programmed by another tuning product and now my Scorcher programmer doesn’t work.
  • Page 24 My vehicle has several aftermarket parts not made by aFe and after I program with Scorcher, the vehicle does not run well. Solution: A Scorcher programmer is designed to work with aFe manufactured bolt-on parts such as throttle body spacers, cold air intakes, and catback exhaust systems.
  • Page 25 I left my Scorcher tuner in my vehicle and went to my dealer for service, now my programmer will not work. Solution: The dealership likely updated your vehicle’s calibrations – sometimes to improve drivability, emissions or safety features and saved over the Scorcher tuning.

  • Page 26: Questions And Answers

    Q: What aftermarket accessories will my Scorcher programmer work with? A: aFe Power programmers are engineered to work with the following parts right out of the box: throttle body spacers, shorty headers, cat-back exhaust system, and cold air intake kit.
  • Page 27 Q: Why do you say you support my truck, but it doesn’t seem to work on my cab and chassis? A: Scorcher supports ‘complete’ truck lines such as Ford F-150, GM C/K 1500 and Dodge Ram 1500. We do not support cutaway, cab and chassis for pickups built from cab and chassis frames.

  • Page 28: Limited Warranty

    Power. Any modifi cation to this item, or if it is used on an application other than what aFe Power markets the product, the warranty will be void. It is the sole responsibility of the customer to determine that this item will work for the application they are intending.

  • Page 29: Service

    If something goes wrong with your product during the warranty period, use the following procedure to return the product to aFe Power: 1. Call the aFe Power Professionals at 951.493.7155 Monday through Friday from 7:00am to 5:00pm PST to request a Return Authorization (RA) number.

  • Page 30: Satisfaction Guarantee

    Satisfaction Guarantee If for any reason during the fi rst thirty (30) days after your purchase of a new aFe Power “Product”, you may return it to the place of purchase for a full refund of the purchase price, credit or a replacement Product at the dealer’s discretion. This Guarantee does not apply to Products purchased from auctions websites nor does it apply to Products purchased used.
  • Page 31 • Do not exceed proper operating conditions. • Equip your vehicle with proper speed rated tires. • Do not stack aFe Power tuning with another tuning product. Doing so may result in damage to your vehicle or unpredictable powertrain results.
  • Page 32 Automotive Tuning www.afepower.com 252 Granite Street • Corona, CA 92879 • Phone 951.493.7155 • Fax 951.493.7177...
