- Page 1 Operating Instructions DUBLIRET REITEL Feinwerktechnik GmbH Senfdamm 20 - 49152 Bad Essen Phone: +49(0)5472-9432-0 - Fax: +49(0)5472-9432-40 http://www.reitel.com - info@reitel.com...
- Page 2 Dear Customer! The DUBLIRET offers precise electronic temperature control for melting duplicating gel, continuously kept at the proper temperature and quick recooling. Heating and working temperature are individually set with the control electronics. Opening the lid a security switch immediately stops the stirrer.
-
Page 3: Table Of Contents
CONTENTS EQUIPMENT ......................... 4 ....................... 4 ASIC QUIPMENT ....................4 PECIAL CCESSORIES SAFETY NOTES ......................5 .................... 5 ENERAL AFETY OTES ................. 5 PECIFIC AFETY NSTRUCTIONS INSTALLATION ......................7 NOTES FOR THE USER ....................7 ........................7 ISPLAY ) ....9 ETTING WORKING TEMPERATURE HEATING AND HOLDING TEMPERATURE ................ -
Page 4: Equipment
Equipment Basic Equipment • Duplicating unit DUBLIRET with electronic temperature control and power cord Special Accessories • Order-No.: 90400 REITEL-GEL GREEN... -
Page 5: Safety Notes
Safety Notes General Safety Notes • All equipment undergoes final inspection and testing before leaving our factory. However, if equipment is damaged during shipping or through any other circumstances, it must not be used in service. Please check the device regularly for damages. Damaged parts should be replaced immediately. - Page 6 • Prior to using the duplicating unit fill in duplicating gel. Don’t overfill the unit.
-
Page 7: Installation
Installation The electric equipment is being delivered fully installed. The sealed plug can be connected directly to the mains supply 230 V/16 A. For installation please refer to safety instructions in chapter 2. Notes for the User Display Programming button: Press button P to display storage SP 1 (heating temperature) and SP 2 (holding temperature), dependent on the current heating level. - Page 8 LED OUT 1: signalises heating level for SP 1 (heating temperature). After reaching set temperature the display jumps to LED OUT 2 and LED OUT 3. LED OUT 2: signalises cooling level. After reaching the holding temperature, display goes off. LED OUT 3: signalises cooling level and for SP 2 (holding temperature).
-
Page 9: Setting Working Temperature (Heating And Holding Temperature)
Setting working temperature (heating and holding temperature) 1. Turn power switch (4) to on. 2. Press key P to get into programming mode. The upper display indicates SP 1 (during heat-up phase) or SP 2 (during cooling/holding phase). Use the arrow keys to modify set value in the lower display. -
Page 10: Troubleshooting
Troubleshooting Device doesn’t start. a. Check fuse of the building. b. Check fuse of the appliance. Motor stands still. Check: a. if the lid solenoid (9) is correctly positioned in the cutout of the solenoid (10). b. if the duplicating gel is sufficiently reduced to pieces (if this is not the case, switch off the device before cutting into pieces!) -
Page 11: Warranty
Warranty We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven date of purchase. This warranty covers all defects traceable to materials, design or workmanship. The following warranty regulations are applicable: Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees at its sole option, to perform repair or replace this product at no charge covering all defects traceable to materials, design or workmanship. - Page 12 REITEL Feinwerktechnik GmbH; − The warranty does not cover the cost of removal and replacement of parts and accessories, unless supplied as original equipment by REITEL Feinwerktechnik GmbH − All kind of damages occurred not directly at the device as well as consequential damages (e.g.
- Page 13 Should you need to borrow a device while your device is being repaired, please contact Messrs. REITEL or your distributor. These loans are a service for which availability cannot necessarily be guaranteed. After the warranty period, a free may be charged for loan...
-
Page 14: Rules For Disposal Of Commercial Electrical Equipment
Rules for Disposal of Commercial Electrical Equipment According to valid laws our devices are disposed of according to B2B – regulations for proper disposal. Pls. contact your local dealer for additional information. Technical Data Line voltage 230 V/50–60 Hz Current consumption 700 W Height/width/depth 430/290/420 + 30 mm... -
Page 15: Operating Elements
Operating Elements Temperature control with display Extraction piston with drain tap Extraction channel Power switch Fuses Container lid Stirrer Lid‘s solenoid 10 Solenoid switch... -
Page 17: Spare Parts List
Motorträger unten für Dubliret Stck E76997 Lower motor mount for Dubliret piece Motorwelle Dubliret D12x64 Stck E76996 Motor shaft Dubliret D12 x 64 piece O- Ring für Entnahmekolben Stck E78510 O-rig for discharge piston piece Pilzknopf VA Stck E78506... - Page 18 Thermoschalter, schließer 50°C (4) Temperature switch with closable electric contacts Stck E74067 50°C (4) piece Transformator 230V/24V Stck E66132.2 Transformer 230 V/24 V (4) piece Umbausatz für Antrieb Dubliret Stck E77000 Drive retrofit kit for Dubliret piece Zuleitung Stck E60158 Feed piece...
- Page 20 We manufacture in compliance with Quality Management ISO 9001:2008 incorporating established standards. REITEL Feinwerktechnik GmbH Senfdamm 20 - 49152 Bad Essen Phone: +49(0)5472-9432-0 - Fax: +49(0)5472-9432-40 http://www.reitel.com - info@reitel.com...
